| NO. | Brand | Compatible P/N | Remarks |
| 1 | Huawei | SFP-10G-LR | |
| 2 | Ciena | XCVR-S10V31 | |
| 3 | H3C | SFP-XG-LX-SM1310 | |
| 4 | HPE ProCure | J9151A | |
| 5 | HPE Aruba | J9151D | |
| 6 | Dell | GP-10GSFP-1L | |
| 7 | D-Link | DEM-432XT | |
| 8 | NVIDIA(Mellanox) | MFM1T02A-LR | |
| 9 | EdgeCore | ET5402-LR | |
| 10 | Extreme | 10GB-LRLX-SFPP |
| Dell Compatible | GP-10GSFP-1L | Vendor Name | HYTOPTODEVICE |
| Form Factor | SFP+ | Max Data Rate | 10.7Gbps |
| Wavelength | 1310nm | Max Distance | 10km |
| Connector | Duplex LC | Transmitter Type | 1310nm DFB |
| Cable Type | OS2 SMF | Receiver Type | PIN |
| TX Power | -6.5~-0.5dBm | Receiver Sensitivity | < -14.4dBm |
| Power Consumption | ≤1W | Receiver Overload | 0.5dBm |
| Protocols | IEEE 802.3ae, SFF-8472, SFF-8431, SFF-8432, SFP+ MSA Compliant, CPRI, eCPRI | Operation Temperature | 0 to 70°C (32 to 158°F) |
Usage Guidelines & Best Practices
Fiber Compatibility: Designed exclusively for G.652 OS2 single-mode fiber. Multimode fibers (OM3/OM4) or incompatible connector polish types (e.g., APC if the module requires UPC) will cause high attenuation and reduce transmission range.
Maintenance & Polarity: Clean LC optical connectors regularly before insertion. Dust and debris on the end face can lead to signal loss and degrade SFP+ 10G LR performance.
Distance & Link Budget: Supports up to a 10 km transmission distance within the standard optical power budget. Excessive fiber splices, patch panels, or sharp bends will shorten the usable range.
Thermal Management: Operating power consumption is ≤ 1 W, requiring no additional heat sinks under standard commercial temperatures (0°C to 70°C).
Industrial Grade Option: For outdoor cabinet deployments requiring extreme temperatures, contact sales for our industrial-grade (-40°C to 85°C) SFP+ 10G LR modules.
“Phenomenal performance. We deployed 200 HYTOPTODEVICE SFP modules to replace Cisco OEMs in our backbone network. Result? Zero compatibility issues and a 60% reduction in costs. Highly recommended for mission-critical networks."— Senior Network Engineer, Regional Telecom, Australia
Quality Certification & Compliance
At HYTOPTODEVICE, our quality commitment is backed by industry-standard validations. From fiber optical transceiver manufacturing to final visual inspection, from IQC、IPQC、FQC to OQC, our processes ensure global compliance and reliability.
We adhere to rigorous standards for our SFP modules and network solutions:
ISO 9001: Certified quality management and production consistency.
CE & FCC: Fully compliant for seamless Global Market Access.
RoHS: Committed to environmental responsibility and hazardous material control.
Proven Reliability: Rigorous testing to reduce compliance risk and ensure safety.
Certified Quality. Global Standards. Guaranteed Performance.
