| NO. | Brand | Compatible P/N | Transceiver Type |
| 1 | Cisco | SFP-10G-SR | SFP-10G-SR(Alcatel) |
| 2 | Cisco | SFP-10G-SR-S | SFP-10G-LR |
| 3 | Cisco | SFP-10G-SR-X | SFP-10G-LRM |
| 4 | Cisco | SFP-10G-SR-I | SFP-10G-ER |
| 5 | Arista Networks | SFP-10G-SR | SFP-10G-ZR |
| 6 | Brocade | 10G-SFPP-SR | |
| 7 | Huawei | SFP-10G-USR | |
| 8 | HP Procurve | J9150A |
The Difference:SFP-10G-SR vs SFP-10G-SR-S vs SFP-10G-SR-X vs SFP-10G-SR-I
Key Technical Specifications
|
Cisco Compatible |
SFP-10G-SR-I |
Vendor Name |
HYTOPTODEVICE |
| Form Factor | SFP+ | Max Data Rate | 10.7Gbps |
| Wavelength | 850nm | Max Distance | 300m on OM3 |
| Connector | Duplex LC | Transmitter Type | VCSEL 850nm |
| Cable Type | MMF | Receiver Type | PIN |
| TX Power | -6.5~-0.5dBm | Receiver Sensitivity | < -10.5dBm |
| Power Consumption | ≤1W | Operation Temperature | -40 to 85°C (-40 to 185°F) |
Usage Guidelines & Best Practices
Fiber Choice: Duplex LC Multimode Fiber (MMF) — OM3 / OM4 (50/125 µm). Do NOT use SMF.
Connector Match: UPC/PC polish only. Do NOT use APC.
Cleanliness & Dust: Keep dust caps on whenever unattached. Clean fiber end-faces with a optical cleaning pen before insertion; dust causes over 80% of optical link failures.
Link Setup:Set speed to 10Gbps Full Duplex. Lock speed manually if auto-negotiation fails.
Handling: Wear ESD protection. Keep fiber bend radius ≥ 30 mm.
Installation & Hot-Swap Rules: MSA hot-swappable. Insert/remove gently without powering down.
Environment: Industrial grade (-40°C to 85°C). Avoid extreme heat, moisture, and dust.
Full Compatibility List and Supported Devices
1. Supported Hardware & Firmware
Main Application Scenarios
• Industrial control network 10G fiber uplink for factory automation
• Outdoor unconditioned cabinet rack-to-rack interconnection
• Harsh-environment 10G SAN storage and virtualization cluster links
• Mining, transportation and energy sector multimode fiber networking
• Bulk supply of Cisco compatible SFP-10G-SR-I transceiver for global industrial buyers via our professional cisco 10gbase-sr sfp+ supplier service













FAQ
Q1: Can this industrial‑rated multirate 10G optic run on various brands of industrial and enterprise network gear?
A: YES. It passes real-machine testing for Cisco IE, Nexus, Catalyst, Arista, Juniper and Dell. We offer two EEPROM versions; share your switch model and firmware for pre-matching when sourcing cross-brand industrial 10GBASE-SR optics from our cisco 10gbase-sr sfp+ supplier.
Q2: Will pairing this industrial 10G multirate module with legacy 1G SFP‑SX optics create valid fiber links?
A: NO. Speed and modulation mismatch stop link negotiation. Always match transceiver speeds on both ends for industrial multirate 10G SFP+ SR modules from our cisco 10gbase-sr sfp+ supplier.
Q3: Does deploying third‑party SFP‑10G‑SR‑I industrial optics invalidate original network‑equipment manufacturer hardware warranty?
A: NO. Base hardware warranty remains intact unless the module damages the port. We provide factory test reports for compliance audits on bulk rugged SFP-10G-SR-I transceivers from our cisco 10gbase-sr sfp+ supplier.
Q4: What should operators do when receiving "unsupported transceiver" alerts on Cisco IE‑series industrial switches?
A: Avoid forcing alarm suppression. Our pre-coded Cisco-I industrial EEPROM variant achieves zero-alarm operation for site rollout of pre-programmed SFP-10G-SR-I optics from our cisco 10gbase-sr sfp+ supplier.
Q5: Am I able to fetch real‑time optical operational parameters from this industrial‑grade SFP‑10G‑SR‑I multirate transceiver?
A: YES. DDM is enabled to monitor power and temperature. Check switch firmware if readings fail to load for DDM-supported industrial 10GBASE-SR SFP+ optics from our cisco 10gbase-sr sfp+ supplier.
Q6: Which fiber‑cable categories are suitable for deployment together with SFP‑10G‑SR‑I industrial multirate optical transceiver?
A: Multimode fiber only. OM3 supports 300m, OM4 reaches 400m. OM4 is recommended for new industrial cabling projects for wholesale 10G SR multimode transceivers from our cisco 10gbase-sr sfp+ supplier.
Q7: Is it acceptable to implement this multimode‑optimized industrial 10G transceiver over existing single‑mode fiber cabling infrastructure?
A: NO. The 850nm VCSEL cannot transmit effectively over single-mode fiber. Choose LR single-mode modules for SMF cabling scenarios from our cisco 10gbase-sr sfp+ supplier.
Q8: What is the emitting‑light wavelength specification for this Cisco‑compatible industrial SFP‑10G‑SR‑I transceiver?
A: 850nm, Class 1 laser. Deploy matching 850nm SR transceivers and use DDM to track laser health under fluctuating field temperatures for wide-temperature 10GBASE-SR optics from our cisco 10gbase-sr sfp+ supplier.
Q9: What physical fiber‑connector interface does industrial‑grade SFP‑10G‑SR‑I adopt?
A: Duplex LC-UPC. Do not mix APC connectors and avoid TX/RX reversal for LC interface industrial 10GBASE-SR SFP+ transceivers from our cisco 10gbase-sr sfp+ supplier.
Q10: Does SFP‑10G‑SR‑I industrial multirate transceiver achieve normal interoperability with OM5 lime‑green wide‑band multimode patch cords?
A: YES. OM5 works well with this module; maximum distance stays at 400m for OM5 compatible industrial 10G SR transceivers from our cisco 10gbase-sr sfp+ supplier.
Q11: How much power will this full‑industrial‑grade 10G SFP+ SR‑I consume under maximum traffic loading?
A: ≤1.0W, low power for high-density industrial ports. Monitor temperature via DDM for low-power industrial 10GBASE-SR SFP+ modules from our cisco 10gbase-sr sfp+ supplier.
Q12: What temperature‑grade variants are offered for this compatible SFP‑10G‑SR‑I optical component?
A: -40~85℃ industrial grade in stock. Extended and commercial temperature versions are available by custom order for variable-temperature 10GBASE-SR optics from our cisco 10gbase-sr sfp+ supplier.
Q13: Can this harsh‑environment multirate optic satisfy strict industrial‑data‑center bit‑error‑rate performance criteria?
A: YES, BER ≤1×10⁻¹², compliant with IEEE 802.3ae. Burn-in testing is available before shipment for industrial data center 10G SR transceivers from our cisco 10gbase-sr sfp+ supplier.
Q14: Can SFP‑10G‑SR‑I industrial‑grade optic deliver full bidirectional multirate line‑rate under its supported protocol modes?
A: YES, stable 9.83–11.31Gbps multirate. Confirm your Cisco IE switch firmware supports this profile before bulk purchase of multi-protocol industrial 10GBASE-SR modules from our cisco 10gbase-sr sfp+ supplier.
Q15: What link‑failure symptoms will appear when incoming received optical power falls below the industrial‑module sensitivity threshold?
A: Link flapping or port down. Inspect fiber cleanliness, patch cords and laser aging when Rx power is insufficient for industrial SFP-10G-SR-I transceivers from our cisco 10gbase-sr sfp+ supplier.
Packaging & Custom OEM Solutions
Every 10G SFP+ module comes individually sealed in standard anti-static (ESD-safe) packaging, pre-stocked and ready for immediate shipment. For bulk orders, we offer custom OEM packaging—including logo printing and private labeling—tailored for network distributors, system integrators, and enterprise deployments.
