What Is Cisco Compatible DS-SFP-FC10G-LW Optical Transceiver?
SFP+ Transceiver | Cisco Compatible 10G Optical Transceiver Module(SMF, 1310nm, 10km, LC, DOM) | HYTOPTODEVICE
The DS-SFP-FC10G-LW is a high-performance, MSA-compliant Cisco-compatible 10G Fibre Channel SFP+ transceiver. Featuring a hot-pluggable SFP+ form factor, it supports up to 10km link lengths over LC duplex SMF with a 1310nm wavelength. With low-latency and low power consumption, this transceiver is specially engineered for Storage Area Networks (SAN),High-Performance Disaster Recovery (DR) and MDS Switch-to-Switch Inter-Switch Links (ISL). Compliant with both the SFP+ Multi-Source Agreement (MSA) and SFF-8431, SFF-8432 and IEEE 802.3ae standards. DOM (Digital Optical Monitoring) supported.
Key Technical Specifications of 10GBASE-LR Optical Transceiver
| Cisco Compatible |
DS-SFP-FC10G-LW |
Vendor Name |
HYTOPTODEVICE |
| Form Factor |
SFP+ |
Max Data Rate |
10.7Gbps |
| Wavelength |
1310nm |
Max Distance |
10km |
| Connector |
Duplex LC |
Transmitter Type |
1310nm DFB |
| Cable Type |
OS2 SMF |
Receiver Type |
PIN |
| TX Power |
-6.5~-0.5dBm |
Receiver Sensitivity |
< -14.4dBm |
| Power Consumption |
≤1W |
Operation Temperature |
0 to 70°C (32 to 158°F) |
Full Compatibility List and Supported Devices of 10G Fiber Optic Transceiver
One of the biggest advantages of third-party optical transceiver is their strong brand compatibility,which helps enterprises cut hardware costs without sacrificing performance. Worried about compatibility? Don't be. We deliver verified results on real hardware. Video proof available upon request.Our sfp 10g lr module is fully tested and certified to work seamlessly with the following Cisco hardware:
-
Cisco MDS 9000 Series Multilayer Directors: Fully compatible with MDS 9700 Series (e.g., MDS 9706, 9710, 9718) equipped with 10Gbps-capable Fibre Channel switching modules.
-
Cisco MDS 9000 Series Fabric Switches: Fully compatible with standalone storage switches including the MDS 9148S, MDS 9250i, MDS 9396S, and MDS 9132T.
-
Cisco Nexus Storage-Enabled Switches: Compatible with unified fabric ports on Cisco Nexus 5000, 7000, and 9000 Series switches operating in Fibre Channel or FCoE modes.
Main Application Scenarios of SFP 10G LR
-
Storage Area Network (SAN) Interconnect: Bridges the physical distance between primary storage arrays and remote backup systems across campus networks or colocation data centers up to 10km.
-
High-Performance Disaster Recovery (DR): Enables real-time, synchronous or asynchronous data replication over single-mode fiber links to prevent data loss.
-
MDS Switch-to-Switch Inter-Switch Links (ISL): Aggregates bandwidth by linking multiple distributed Cisco MDS fabric switches together into a unified storage architecture.
Connectivity Solutions(Applications) of 1310nm 10km SFP+
FAQ for SFP-10G-LR
Q1: What makes SFP‑10G‑LR different from DS‑SFP‑FC10G‑LW transceivers?
A1: The core difference lies in supported transmission protocols. SFP‑10G‑LR is engineered for regular 10G Ethernet network deployments. DS‑SFP‑FC10G‑LW is dedicated to Fibre Channel storage networks and runs at the unique 10.518 Gbps Fibre Channel line rate.These two modules cannot be swapped for use on non‑unified switch ports.Bulk and long-term supply available for these two compatible modules from HYTOPTODEVICE
Q2: What does the suffix “LW” mean in the DS‑SFP‑FC10G‑LW part number?
A2: LW is short for Long‑Wave or Long‑Wavelength in Fibre Channel naming rules. Long‑Wave optics are designed for single‑mode fiber links at 1310nm, supporting transmission up to 10 kilometers.In contrast, SW (Short‑Wave) refers to multi‑mode fiber transceivers used for short‑distance connections.
Q3: Does installing a third‑party compatible DS‑SFP‑FC10G‑LW transceiver void the warranty of my Cisco MDS switch?
A3: No, it will not. Under relevant consumer protection regulations, hardware vendors are not allowed to invalidate device warranties only because users select reliable third‑party compatible optical transceivers. Our modules match OEM‑level stability while offering a more cost‑effective solution.
Q4: How can I confirm your compatible DS‑SFP‑FC10G‑LW works well with my Cisco MDS switch?
A4: Compatibility is fully guaranteed.
Every batch of our transceivers is tested on real Cisco MDS hardware before delivery.
We can also provide real‑world test videos showing stable module recognition and normal data transmission in live MDS switch environments if you require.
Q5: Is DOM monitoring available for this module on Cisco MDS supervisor modules?
A5: Yes, our compatible DS‑SFP‑FC10G‑LW supports full Digital Optical Monitoring (DOM).
You can check key parameters such as laser working status, transmit and receive optical power, and module temperature through NX‑OS commands like show interface transceiver details.
Q6: Which fiber cable is suitable for DS‑SFP‑FC10G‑LW connection?
A6: A duplex LC‑to‑LC single‑mode fiber patch cord is the basic requirement. For stable signal transmission over the full 10‑km reach, OS2 grade 9/125µm single‑mode fiber is strongly recommended.
Q7: Can DS‑SFP‑FC10G‑LW operate at lower Fibre Channel speeds such as 8G, 4G or 2G?
A7: No. DS‑SFP‑FC10G‑LW is a fixed‑rate 10G Fibre Channel transceiver. It cannot be downgraded to support 8G, 4G or 2G Fibre Channel speeds.
Why Network Engineers Choose HYTOPTODEVICE
HYTOPTODEVICE has supplied over 5000,000 optical transceiver modules to data centers, ISPs, and enterprise networks across 100+ countries since 2011. Every module undergoes a 72-hour burn-in test and full DDM/DOM validation before shipment.
- 100% MSA-compliant modules with Cisco, Huawei,Dell,Juniper, and Arista compatibility
- ISO 9001:2015 certified manufacturing facility in Shenzhen
- Average lead time of 3–5 business days with DHL/FedEx express options
- Dedicated pre-sales engineering support for custom configurations
- Actual hardware,actual switches,actual results.we publish compatibility test video,eliminate compatibility anxiety. you can watch before you buy.
- We can provide inspection and shipping videos to make you feel as if you are right here with the product.
- Private Label support - EEPROM / firmware customization suppor
“Phenomenal performance. We deployed 200 HYTOPTODEVICE SFP+ modules to replace Cisco OEMs in our backbone network. Result? Zero compatibility issues and a 60% reduction in costs. Highly recommended for mission-critical networks."— Senior Network Engineer, Regional Telecom, Australia
Quality Certification & Compliance
At HYTOPTODEVICE, our quality commitment is backed by industry-standard validations. From fiber optical transceiver manufacturing to final visual inspection, from IQC、IPQC、FQC to OQC, our processes ensure global compliance and reliability.
We adhere to rigorous standards for our SFP modules and network solutions:
-
ISO 9001: Certified quality management and production consistency.
-
CE & FCC: Fully compliant for seamless Global Market Access.
-
RoHS: Committed to environmental responsibility and hazardous material control.
-
Proven Reliability: Rigorous testing to reduce compliance risk and ensure safety.
Certified Quality. Global Standards. Guaranteed Performance.
