| NO. | Brand | Compatible P/N | Remarks |
| 1 | Cisco | SFP-10G-BXU | |
| 2 | H3C | SFP-XG-LX-SM1270-BIDI | |
| 3 | Ubiquiti | UACC-OM-SM-10G-S-U | |
| 4 | Huawei | SFP-10G-BXU1 | |
| 5 | Juniper | JNP-SFP-10G-BX10U | For Enterprise |
| 6 | Juniper | EX-SFP-10GE-BX23-20 | For Data Center |
| 7 | Dell | GP-SFP-10GBX-U-10 | |
| 8 | Brocade | 10G-SFPP-BXU | |
| 9 | Extreme | 10GB-BX10-U | |
| 10 | MikroTik | S+2332LC10U | |
| 11 | Arista | SFP-10G-BXU |
Compatibility and Supported Devices
The HYTOPTODEVICE S+2332LC10D compatible module is extensively tested for "Plug-and-Play" operation on:
MikroTik Cloud Core Routers (CCR): CCR1036-8G-2S+, CCR1009-7G-1C-1S+, CCR2004-16G-2S+, and the flagship CCR2216-1G-12XS-2XQ.
MikroTik Cloud Router Switches (CRS): CRS317-1G-16S+RM, CRS305-1G-4S+IN, and CRS326-24S+2Q+RM.
MikroTik Edge Equipment: RB4011 series and CCR2116.
Broad Compatibility: Also works flawlessly with Ubiquiti EdgeSwitch, UniFi Dream Machine Pro (UDM-Pro), and TP-Link JetStream switches.
WISP Backhaul Links: Optimize Wireless ISP backhaul by doubling bandwidth on single-strand fiber towers using 10G BiDi 1270/1330nm technology.
ISP Last Mile Connectivity: Efficiently deploy 10Gbps Fiber-to-the-Home (FTTH) or business premium services using MikroTik CCR gateways.
Data Center Top-of-Rack (ToR): Connect MikroTik CRS317 switches in high-density racks with reliable 10km SFP+ BiDi optics.
Campus Network Aggregation: Reduce cabling costs by 50% in campus environments by upgrading from dual-fiber to HYTOPTODEVICE single-fiber BiDi modules.
Key Product Parameters
| MikroTik Compatible | S+2332LC10U | Vendor Name | HYTOPTODEVICE |
| Form Factor | SFP+ | Max Data Rate | 10.7Gbps |
| Wavelength | TX1270nm/RX1330nm | Max Distance | 10km |
| Connector | Simplex LC | Transmitter Type | 1270nm DFB |
| Cable Type | SMF | Receiver Type | PIN |
| TX Power | -5.0~0dBm | Receiver Sensitivity | < -14.4dBm |
| Max. Power Consumption | ≤1W | Receiver Overload | 0.5dBm |
| Protocols | 10G Ethernet, MSA Compliant | Operation Temperature | 0 to 70°C (32 to 158°F) |
Q1: Is this module compatible with the MikroTik "SFP ignore" command? A: No need! HYTOPTODEVICE modules are coded to be natively recognized by RouterOS. They will show up as a valid 10G link without requiring special CLI overrides.
Q2: Can I use the S+2332LC10D at both ends of the fiber? A: No. You must pair this 1270nm-TX module with its matching "Downstream" partner, the S+3223LC10D (1330nm-TX).
Q3: Does MikroTik RouterOS show the DDM temperature and voltage for this module? A: Yes. Under the /interface ethernet monitor tab, you can view real-time DOM data (TX/RX power, temperature) provided by the HYTOPTODEVICE hardware.
Q4: Will this work in a 1G SFP port? A: This is a fixed 10G SFP+ module. While some MikroTik ports are dual-speed, this module is optimized for 10Gbps Ethernet performance.
Q5: How does HYTOPTODEVICE handle heat dissipation compared to original MikroTik modules? A: Our modules are designed with high-quality heat-sink housing to maintain a stable 0-70°C operating range, preventing the thermal throttling often seen in low-quality generics.
Quality Assurance：Your Trusted Optical Transceiver Source
HYTOPTODEVICE is a vertically integrated manufacturer of high-performance optical transceivers. By controlling core materials at the source, we ensure every SFP module meets the highest standards of reliability and customization.
Vertical Integration: In-house core material production ensures a stable, self-sufficient supply chain for all optical modules.
Total Traceability: End-to-end oversight from raw components to final transceiver assembly guarantees 100% controllability.
Bespoke Solutions: Expert-led R&D provides customized SFP transceiver designs tailored to your specific technical needs.
24-Hour Response: Our technical team guarantees a primary response to any inquiry or quality concern within 24 hours.
Carrier-Grade Quality. Factory-Direct Control. Rapid Response.
Quality Certification & Compliance：
At HYTOPTODEVICE, our quality commitment is backed by industry-standard validations. From fiber optical transceiver manufacturing to final inspection, our processes ensure global compliance and reliability.
We adhere to rigorous standards for our SFP modules and network solutions:
ISO 9001: Certified quality management and production consistency.
CE & FCC: Fully compliant for seamless Global Market Access.
RoHS: Committed to environmental responsibility and hazardous material control.
Proven Reliability: Rigorous testing to reduce compliance risk and ensure safety.
Certified Quality. Global Standards. Guaranteed Performance.
