Cisco QDD-800G-DR8 Compatible 800G QSFP-DD DR8 8 x 100G PAM4 Optical Transceiver Module | HYTOPTODEVICE

Product Detail：
HYTOPTODEVICE 800G Transceiver | Cisco Compatible 800BASE-DR8 QSFP-DD Optical Transceiver Module (SMF, 1310nm, 500m, MPO-16 APC, DOM)
      The HYTOPTODEVICE QDD-800G-DR8 is a high-performance Cisco compatible 800G optical transceiver, engineered for next-generation 800G Ethernet, Data Center Interconnect (DCI), and InfiniBand Interconnects.it transmit traffic up to 500m over OS2 single-mode fibre (SMF) using a wavelength of 1310nm via MTP/MPO-16 APC connectors. Fully compliant with IEEE P802.3ck, IEEE 802.3cu, QSFP-DD MSA standards.supporting real-time DDM.
      The 800G QSFP-DD transceiver supports 2x 400G DR4 and 8x 100G DR breakout applications.It can split into two separate 400Gbps connections, each running over 4 lanes of parallel single-mode fiber (DR4) or split into eight individual 100Gbps connections. Featured with low latency, low power, and reliability, perfect for 800G Ethernet, Data Center, high-performance computing networks, enterprise core and distribution layers, and service provider applications.

Full Compatibility List and Supported Devices of 800G Fibre Optics

This module is 100% programmed and tested to be compatible with Cisco’s premier 800G-enabled hardware portfolios running NX-OS or IOS-XR, including:

• Cisco Nexus 9000 Series Switches:

  • Nexus 9364E-SG2

  • Nexus 9332D-H2R

  • Nexus 9808 / 9804 Modular Chassis (with 800G line cards)

• Cisco 8000 Series Routers:

  • Cisco 8111-32EH (32-port 800G QSFP-DD fixed router)

  • Cisco 8200 / 8800 Series (with high-density 800G line cards)

• Cisco NCS (Network Convergence System):

  • NCS 1004 / 1014 Series (with 800G transponder line cards)

Primary Application Scenarios

• AI/ML Hyper-scale Training Fabrics: Provides the high-throughput, low-latency plumbing required to connect massive multi-GPU/TPU clusters performing distributed LLM training.

• Data Center Spine-Leaf Interconnects: Enables ultra-dense 800G uplinks from modern leaf switches to spine switches, eliminating bandwidth bottlenecks inside data center architectures.

• High-Flexibility Breakout Deployments: Supports versatile breakout configurations to seamlessly bridge legacy and next-gen hardware:

  • 2x 400G DR4 breakout to 400G switches/routers.

  • 8x 100G DR breakout to 100G server NICs or aggregation layers.

• High-Performance Computing (HPC): Delivers highly reliable, high-speed data pipelines for storage networks, scientific research arrays, and cloud-based computing grids.



Key Product Parameters

Q1:  800G DR8 VS 800G FR4, What is the primary difference ? A1: The primary differences are fiber type layout and distance. DR8 uses parallel optics (8 lanes of 100G running over 8 pairs of single-mode fiber) and reaches up to 500 meters. It is ideal for short-reach high-density environments and allows 8x100G or 2x400G breakouts. FR4 uses coarse wavelength division multiplexing (CWDM) over a single duplex LC fiber pair to reach up to 2km, but it does not natively breakout into 8 individual 100G lines.

Q2: Does this module support backward compatibility or breakout configurations? A2: Yes. The 800G DR8 module is highly flexible. It can be software-configured on the switch port to operate at full 800G speed, split into 2x 400G (DR4) links, or broken out into 8x 100G (DR) independent channels using an MPO breakout patch cable.

Q3: What type of fiber connector does this Cisco compatible module use? A3: The standard standard-density 800G QSFP-DD DR8 module utilizes an MPO-16 (APC) connector interface.

Q4: Is this module hot-swappable, and does it support DOM? A4: Yes, it is fully hot-pluggable, meaning it can be installed or removed without powering down the switch. It also features built-in Digital Optical Monitoring (DOM/DDM), allowing network administrators to monitor real-time metrics like TX/RX optical power, temperature, and voltage via the Cisco CLI.

Why Network Engineers Choose HYTOPTODEVICE

HYTOPTODEVICE has supplied over 5000,000 optical transceiver modules to data centers, ISPs, and enterprise networks across 100+ countries since 2011. Every module undergoes a 72-hour burn-in test and full DDM/DOM validation before shipment.

• 100% MSA-compliant modules with Cisco, Huawei,Dell,Juniper, and Arista compatibility
• ISO 9001:2015 certified manufacturing facility in Shenzhen
• Average lead time of 3–5 business days with DHL/FedEx express options
• Dedicated pre-sales engineering support for custom configurations
• Actual hardware,actual switches,actual results.we publish compatibility test video,eliminate compatibility anxiety. you can watch before you buy.
• We can provide inspection and shipping videos to make you feel as if you are right here with the product.

"We replaced 200 Cisco-branded SFPs with HYTOPTODEVICE equivalents across our spine layer — zero compatibility issues, 40% cost reduction."— Network Architect, Tier-2 ISP, Germany

Quality Certification & Compliance：

 At HYTOPTODEVICE, our quality commitment is backed by industry-standard validations. From fiber optical transceiver manufacturing to final inspection, our processes ensure global compliance and reliability.

We adhere to rigorous standards for our SFP modules and network solutions:

• ISO 9001: Certified quality management and production consistency.

• CE & FCC: Fully compliant for seamless Global Market Access.

• RoHS: Committed to environmental responsibility and hazardous material control.

• Proven Reliability: Rigorous testing to reduce compliance risk and ensure safety.

Certified Quality. Global Standards. Guaranteed Performance.
