| NO. | Brand | Compatible P/N | Remarks |
| 1 | Cisco | SFP-10G-BXU | |
| 2 | H3C | SFP-XG-LX-SM1270-BIDI | |
| 3 | Ubiquiti | UACC-OM-SM-10G-S-U | |
| 4 | Huawei | SFP-10G-BXU1 | |
| 5 | Juniper | JNP-SFP-10G-BX10U | For Enterprise |
| 6 | Juniper | EX-SFP-10GE-BX23-20 | For Data Center |
| 7 | Dell | GP-SFP-10GBX-U-10 | |
| 8 | Brocade | 10G-SFPP-BXU | |
| 9 | Extreme | 10GB-BX10-U | |
| 10 | MikroTik | S+2332LC10U | |
| 11 | Arista | SFP-10G-BXU |
Compatibility and Supported Devices
UniFi Ecosystem: Full Ubiquiti UDM Pro SFP+ compatibility, as well as the UniFi Switch Integration (USW-Pro, USW-Enterprise).
EdgeSwitch Series: Native HYTOPTODEVICE EdgeSwitch 10G BiDi support for the ES-16-XG and ES-48-Port models.
System Pairing: To establish a link, this U-Tx1270 module must be paired with the HYTOPTODEVICE UACC-OM-SM-10G-S-D (Downstream, Tx1330/Rx1270) at the other end.
UniFi Network Expansion: Perfect for HYTOPTODEVICE Ubiquiti UniFi 10G deployment where you need to link two Dream Machine Pro (UDM-Pro) or UniFi Aggregation switches over a single fiber core.
Cost-Efficient Backhaul: Ideal for creating a single strand fiber 10G backbone between buildings in a corporate campus or school district.
ISP & WISP Uplinks: Frequently used by service providers to deliver 10G handoffs to customers using only one fiber strand to maximize port density.
Key Product Parameters
| Ubiquiti Compatible | UACC-OM-SM-10G-S-U | Vendor Name | HYTOPTODEVICE |
| Form Factor | SFP+ | Max Data Rate | 10.7Gbps |
| Wavelength | TX1270nm/RX1330nm | Max Distance | 10km |
| Connector | Simplex LC | Transmitter Type | 1270nm DFB |
| Cable Type | SMF | Receiver Type | PIN |
| TX Power | -5.0~0dBm | Receiver Sensitivity | < -14.4dBm |
| Max. Power Consumption | ≤1W | Receiver Overload | 0.5dBm |
| Protocols | 10G Ethernet, MSA Compliant | Operation Temperature | 0 to 70°C (32 to 158°F) |
Q1: What is the difference between UACC-OM-SM-10G-S-U and S-D? A: The difference between UACC-OM-SM-10G-S-U and S-D is the wavelength. The -U (Upstream) transmits at 1270nm and receives at 1330nm. The -D (Downstream) does the opposite. You must use one of each to create a functional connection.
Q2: Can I use this Ubiquiti BiDi module in a standard 1G SFP port? A: No. This is a 10G SFP+ module. For Ubiquiti UACC-OM-SM-10G-S-U compatibility, the host device must have an SFP+ port capable of 10Gbps speeds.
Q3: Does the HYTOPTODEVICE version support Real-Time Monitoring? A: Yes. It includes Digital Optical Monitoring (DOM), allowing you to track signal strength and the UACC-OM-SM-10G-S-U operating temperature directly through the UniFi OS or EdgeOS dashboard.
Q4: Is this module suitable for outdoor pole-mounted switches? A: Since this is a commercial grade transceiver, it should be used in climate-controlled environments (0-70°C). For unconditioned outdoor cabinets, an industrial-grade version would be required.
Q5: Where can I buy the HYTOPTODEVICE compatible UACC-OM-SM-10G-S-U? A: For the best price for Ubiquiti UACC-OM-SM-10G-S-U online, choose HYTOPTODEVICE. We offer high-quality, fully tested modules with an industry-leading warranty.
