| NO. | Brand | Compatible P/N | Remarks |
| 1 | Cisco | SFP-10G-BXD | |
| 2 | H3C | SFP-XG-LX-SM1330-BIDI | |
| 3 | Ubiquiti | UACC-OM-SM-10G-S-D | |
| 4 | Huawei | SFP-10G-BXD1 | |
| 5 | Juniper | JNP-SFP-10G-BX10D | For Enterprise |
| 6 | Juniper | EX-SFP-10GE-BX32-20 | For Data Center |
| 7 | Dell | GP-SFP-10GBX-D-10 | |
| 8 | Brocade | 10G-SFPP-BXD | |
| 9 | Extreme | 10GB-BX10-D | |
| 10 | MikroTik | S+2332LC10D | |
| 11 | Arista | SFP-10G-BXD |
Compatibility and Supported Devices
The HYTOPTODEVICE S+2332LC10D is rigorously tested to ensure 100% compatibility with MikroTik platforms:
MikroTik Cloud Core Routers (CCR): CCR2004, CCR2116, CCR2216, and the classic CCR1036/CCR1072 series.
MikroTik Cloud Router Switches (CRS): CRS305, CRS309, CRS317, CRS326, and CRS354 series.
MikroTik Cloud Smart Switches (CSS): CSS326 and CSS610 series running SwOS.
Enterprise Wireless Wire: Interconnecting 10G uplinks for 60G/wireless backhaul systems.
ISP Fiber Aggregation: Using 10G single-strand fiber solutions to deliver high-bandwidth residential or business internet services using MikroTik CCR routers.
Enterprise Core Expansion: Doubling the throughput between two CRS317 switches over a single fiber run in a corporate server room.
WISP Backhaul Upgrade: Providing stable 10Gbps BiDi links for wireless tower backhaul where fiber cores are limited.
Low-Latency Data Center Links: Optimized for high-density environments requiring reliable 10G SFP+ 10km BiDi optics for top-of-rack connectivity.
Key Product Parameters
| MikroTik Compatible | S+2332LC10D | Vendor Name | HYTOPTODEVICE |
| Form Factor | SFP+ | Max Data Rate | 10.7Gbps |
| Wavelength | TX1330nm/RX1270nm | Max Distance | 10km |
| Connector | Simplex LC | Transmitter Type | 1330nm DFB |
| Cable Type | SMF | Receiver Type | PIN |
| TX Power | -5.0~0dBm | Receiver Sensitivity | < -14.4dBm |
| Max. Power Consumption | ≤1W | Receiver Overload | 0.5dBm |
| Protocols | 10G Ethernet, MSA Compliant | Operation Temperature | 0 to 70°C (32 to 158°F) |
Q1: What is the wavelength pairing for the MikroTik S+2332LC10D? A: The S+2332LC10D (Downstream) transmits at 1330nm and receives at 1270nm. For a functional link, it must be paired with the S+2332LC10U (Upstream), which transmits at 1270nm and receives at 1330nm.
Q2: Will MikroTik RouterOS show the DDM information for this module? A: Yes. HYTOPTODEVICE modules are fully compatible with RouterOS (v6 and v7). You can view real-time TX/RX power, temperature, and voltage in the Interfaces -> SFP tab of WinBox or via the CLI.
Q3: Can I use this module in a 1G SFP port? A: No, this is a dedicated 10G SFP+ module. It is designed for 10Gbps ports. While some MikroTik ports are dual-rate, this specific module is optimized for 10G performance.
Q4: Is this module hot-swappable in a running CCR router? A: Absolutely. The module is hot-pluggable, allowing you to insert or remove the transceiver while the MikroTik device is powered on without affecting other network interfaces.
Q5: Why choose HYTOPTODEVICE over original MikroTik optics? A: We offer the same MikroTik SFP+ compatibility and performance at a more accessible price point, backed by rigorous testing on actual MikroTik hardware to ensure carrier-grade reliability.
Quality Assurance：Your Trusted Optical Transceiver Source
HYTOPTODEVICE is a vertically integrated manufacturer of high-performance optical transceivers. By controlling core materials at the source, we ensure every SFP module meets the highest standards of reliability and customization.
Vertical Integration: In-house core material production ensures a stable, self-sufficient supply chain for all optical modules.
Total Traceability: End-to-end oversight from raw components to final transceiver assembly guarantees 100% controllability.
Bespoke Solutions: Expert-led R&D provides customized SFP transceiver designs tailored to your specific technical needs.
24-Hour Response: Our technical team guarantees a primary response to any inquiry or quality concern within 24 hours.
Carrier-Grade Quality. Factory-Direct Control. Rapid Response.
Quality Certification & Compliance：
At HYTOPTODEVICE, our quality commitment is backed by industry-standard validations. From fiber optical transceiver manufacturing to final inspection, our processes ensure global compliance and reliability.
We adhere to rigorous standards for our SFP modules and network solutions:
ISO 9001: Certified quality management and production consistency.
CE & FCC: Fully compliant for seamless Global Market Access.
RoHS: Committed to environmental responsibility and hazardous material control.
Proven Reliability: Rigorous testing to reduce compliance risk and ensure safety.
Certified Quality. Global Standards. Guaranteed Performance.
