Cisco compatible SFP BiDi Transceiver GLC-BX40-DA | 1000BASE-BX 40km Tx1490Rx1310 Factory Wholesale | HYTOPTODEVICE

Cisco compatible GLC-BX40-DA SFP BiDi transceiver, 1G 40km with Tx1490nm Rx1310nm wavelength over LC simplex connector, DOM/DDM supported, 100% compatible with mainstrean brand,real-device tested. Bulk wholesale & OEM customization available for global importers & distributors.
NO. Brand  Compatible P/N Transceiver Type
1 Cisco GLC-BX40-DA SFP-G34-40LD
2 Alcatel-Lucent  SFP-GIG-BX-D40 SFP-G43-10LD
3 Brocade E1MG-1G-BXDA-40 SFP-G43-20LD
4 Juniper Networks  SFP-GE40KT14R13 SFP-G53-10LD
5 Huawei LE2MGSC40ED0 SFP-G53-20LD
6 Cisco GLC-BX40-D-I SFP-G53-40LD
7 Brocade E1MG-1G-BXD-40 SFP-G45-80LD
8 Juniper Networks  SFP-GE40KT15R13 SFP-G45-1BLD
Description

Cisco Compatible GLC-BX40-DA SFP Bidi Transceiver  40km| HYTOPTODEVICE
(SMF, 1490nm-TX/1310nm-RX, Simplex LC, DOM)

Product Overview

This Cisco compatible GLC-BX40-DA is a high-performance sfp bidi transceiver for 40km single-mode fiber transmission. It adopts Tx1490nm / Rx1310nm wavelength and standard simplex LC connector. Fully compliant with MSA, RoHS and CE standards, it supports complete DOM/DDM monitoring and hot plug-and-play. Ideal for enterprise campus networks, building interconnections and remote branch data links.

Key Technical Specifications

Cisco Compatible

GLC-BX40-DA

Vendor Name HYTOPTODEVICE
Form Factor SFP Max Data Rate 1.25Gbps
Wavelength TX1490nm/RX1310nm Max Distance 40km
Connector Simplex LC Transmitter Type 1490nm DFB
Cable Type SMF Receiver Type PIN
TX Power -5.0~0dBm Receiver Sensitivity < -24.0dBm
Protocols SFF-8472 MSA Compliant, IEEE 802.3ah-2004 Operation Temperature 0 to 70°C (32 to 158°F)

For detailed technical specifications, please refer to the Datasheet

Usage Guidelines


Follow standardized operation rules to extend service life and maintain steady link performance of your BiDi SFP Transceiver:

  1. Complementary Pairing Requirement Bidirectional transceivers must be deployed in matched wavelength pairs. This TX1490/RX1310 BiDi SFP Module requires a counterparty TX1310/RX1490 transceiver at the opposite fiber end; mismatched wavelength pairs cannot establish valid fiber links.
  2. Fiber Type Restriction Only use standard 9/125μm single mode fiber (SMF) with LC/UPC patch cords. This transceiver cannot operate normally on multi-mode fiber (MMF), which triggers severe attenuation and persistent random bit errors.
  3. Distance & Attenuation Control Optimized for stable 40km single-fiber links. For lab testing or field deployment under 15km, an external optical attenuator is mandatory to prevent receiver overpowering, signal saturation and permanent internal optical chip damage.
  4. Optical Port Dust Protection LC optical ports and fiber end faces are highly sensitive to dust and fingerprint contamination. Always reinstall protective dust caps on idle module ports and unused fiber connectors after disconnection.
  5. Hot-Plugging Operation Guidance This MSA-compliant BiDi SFP Transceiver supports safe hot swap. Leave several seconds between removal and reinsertion to let Cisco IOS complete full hardware recognition and avoid unexpected link flapping.

For detailed operation instructions, please refer to the User Guide.


Full Compatibility List and Supported Devices

We ensure 100% native compatibility for this Cisco compatible sfp bidi transceiver GLC-BX40-DA. All products are tested on real network devices, and authentic test videos can be provided on request. It works out of the box without extra configuration, error alerts or unstable links.
1.Cisco Compatibility – Supported Models & Series
 Optimized for Cisco IOS and IOS-XE systems, this 40km sfp bidi transceiver is compatible with:
  • Cisco Catalyst 2960, 3560, 3750, 3850, 9200, 9300 series switches
  • Cisco ISR 1900, 2900, 3900, 4000 series routers
  • Cisco ASR 1000, 9000 aggregation switches
  • All Cisco gigabit SFP ports and 10G SFP+ ports (configurable for 1G speed)

2.Multi-Brand Cross-Platform Compatibility
Besides Cisco, this universal sfp bidi transceiver runs reliably on mainstream network devices to adapt to multi-brand network environments:

  • HPE/Aruba: ProCurve, 2930F, 3810M series switches
  • H3C: S5120, S5500, S6800 series switches
  • Juniper: EX, QFX, MX series devices
  • Alcatel-Lucent: OS6860, OS6900 access switches
  • Huawei: S5700, S6700 series (custom compatible firmware available)


Primary Application Scenarios

The cisco compatible sfp bidi module GLC-BX40-DA must be paired with the GLC-BX40-UA.BiDi SFP modules are used in pairs in the below application scenarios, with matching modules of different wavelengths deployed at each end of the link.

  • Enterprise long-distance interconnection: Deploy 40km sfp bidi transceiver for stable links between headquarters and remote branches.
  • Campus and cross-building networking: Use single fiber sfp bidi module to save fiber resources for park and campus construction.
  • Metropolitan access network deployment: Reliable Cisco compatible sfp bidi transceiver for edge network links.
  • Video surveillance transmission: DOM enabled sfp bidi transceiver for steady long-range camera signal delivery.
  • Legacy network upgrade: Plug and play sfp bidi for Cisco to expand and update existing network systems.
  • Large-scale project supply: Provide bulk sfp bidi transceiver for system integrators and engineering contractors.

Connectivity Solutions (Applications)

1.1GbE Switch-to-Switch Connectivity

hytoptodevice 1000base-bx bidi transceiver tx1310rx1490 40km simplex LC smf
2.1GbE Switch to Media Converter Connectivity
hytoptodevice 1.25g bidi sfp module tx1310rx1490 simplex LC

3.1G Structured Cabling
HYTOPTODEVICE 1000BASE-BX BIDI sfp transceiver 40KM SMF

Core Product Features

1. Expand Your Network at Half the Cost

Why lay two fibers when one will do? Our BiDi transceiver carries full-duplex traffic over a single strand, eliminating the need for extra cabling and switch ports. Compatible with leading campus switches and ready to use out of the box, it's the fastest, most affordable way to scale.
hytoptodevice 40km single fiber BiDi optic, reliable manufacturer for bidi transceiver module

2.Double Your Fiber Capacity Without Laying a Single New Strand

Running out of fiber in your campus network? This BiDi transceiver carries both transmit and receive over one strand using integrated WDM technology. No redundant wiring, no extra cable pulls—just more capacity from the infrastructure you already own. Plug in and scale.

Tx1310 Rx1490 40km simplex LC bidi transceiver module from hytoptodevice

3.High-Density, Low-Power Connectivity for Data Centers

Deliver full-duplex Gigabit Ethernet in a compact SFP form factor without straining your power budget. By combining low power draw with reduced heat output, this BiDi SFP lowers cooling overhead and enables higher port density—so you can scale your data center fabric without expanding either your fiber plant or your power footprint.

hytoptodevice supply bulk wholesale 1000base-bx 40km  BIDI transceiver MODULE with low power consumption and high-efficiency

4. Plug-and-Play Compatibility, Zero Friction

Preprogrammed EEPROM eliminates unsupported-module alerts and CLI configuration. Just insert, hot-swap, and go—compatible out of the box with leading switch platforms. Specific Compatibility Video available upon request.

HYTOPTODEVICE compatible  bidi transceiver module 40km SMF simplex lc

5. Tested to Failure, Shipped with Confidence
Rigorous in-house testing in our Test Center on every unit—signal integrity, BER, and temperature cycling. We push it past spec so your network doesn't have to. Built for uptime, delivered with zero surprises.

HYTOPTODEVICE manufacturer offer BiDi transceiver module full aging test for stable 40km single‑fiber operation


FAQ

Q1: Is HYTOPTODEVICE GLC-BX40-DA fully compatible with original Cisco equipment?

A1: Yes. Our Cisco matched sfp bidi transceiver undergoes full real-device testing on Cisco switches and routers. We offer test videos for verification. It works perfectly with native plug-and-play performance.

Q2: What wavelength and transmission distance does GLC-BX40-DA support?

A2: This long range sfp bidi transceiver features Tx1490nm transmit and Rx1310nm receive wavelength, supporting stable 1G transmission up to 40km over standard single-mode fiber.

Q3: Does GLC-BX40-DA support DOM/DDM monitoring function?

A3: Definitely yes. This monitoring-capable sfp bidi transceiver complies with SFF-8472 standard, allowing you to check real-time optical power, temperature and voltage via device system.

Q4: Why cannot the BiDi module establish normal optical link after installation?

A4: Link failure is mainly caused by incorrect wavelength pairing. This upstream single fiber sfp bidi transceiver must be paired with a reverse wavelength module on the opposite end. HYTOPTODEVICE provides free professional pairing guidance.

Q5: Will using third-party GLC-BX40-DA void Cisco device warranty?

A5: No. According to international warranty rules, OEMs cannot void warranty for using qualified replacement sfp bidi transceiver. Our products fully match original specifications to protect your device warranty.

Q6: Can this 1G sfp bidi module run on Cisco 10G SFP+ ports?

A6: This multi-rate compatible sfp bidi transceiver works on Cisco 10G SFP+ composite ports after simple CLI speed adjustment. All units pass related compatibility tests for stable operation.

Q7: Which fiber cable is suitable for GLC-BX40-DA BiDi module?

A7: This module only works with simplex LC sfp bidi matched single-strand fiber cords. Traditional duplex cables cannot establish valid connections.

Q8: How to solve packet loss for short-distance rack cabling?

A8: Packet loss within 10 meters is caused by excessive laser power. We suggest using a professional optical attenuator to optimize signal strength and keep your standard sfp bidi transceiver running steadily.

Q9: What is the overall stability and service life of HYTOPTODEVICE sfp bidi modules?

A9: Our high stability sfp bidi transceiver adopts premium optical components, with MTBF over 1,000,000 hours. Strict factory testing ensures long-term continuous operation for enterprise networks.

Q10: How to get bulk pricing and OEM service for GLC-BX40-DA?

A10: HYTOPTODEVICE supplies wholesale sfp bidi transceiver worldwide. We provide tiered bulk discounts, OEM customization, private labeling and fast global delivery for distributors and project buyers. Contact us for a customized quote.

Packaging & Custom OEM Solutions

Each BiDi module arrives individually sealed in ESD-safe anti-static packaging, ready to go straight onto your shelf. Distributors, wholesalers, and integrators can leverage our flexible OEM program: custom logos, private labeling, branded packaging. We handle the quality; you own the customer relationship.
HYTOPTODEVICE 1000base-bx bidi transceiver  custom packaging

Why Network Engineers Choose HYTOPTODEVICE

HYTOPTODEVICE has supplied over 5000,000 optical transceiver modules to data centers, ISPs, and enterprise networks across 100+ countries since 2011. Every module undergoes a 72-hour burn-in test and full DDM/DOM validation before shipment.

  • Up to 70% cost savings vs OEM, transparent pricing & flexible bulk rates, supported quality returns
  • 100% real-device compatible with Cisco, Huawei,Dell,Juniper, and Arista
  • ISO 9001:2015 Shenzhen factory, full lineup: 1.25G/10G/25G/40G/100G/200G/400G/800G/1.6T transceivers
  • Ample stock, fast global DHL/FedEx shipping in 3–5 working days
  • Free pre-sales engineering support for custom EEPROM  & private label firmware
  • Real switch test videos available for pre-purchase review; inspection & shipping videos provided per order

“Phenomenal performance. We deployed 200 HYTOPTODEVICE SFP modules to replace Cisco OEMs in our backbone network. Result? Zero compatibility issues and a 60% reduction in costs. Highly recommended for mission-critical networks."— Senior Network Engineer, Regional Telecom, Australia


Quality Certification & Compliance

 At HYTOPTODEVICE, our quality commitment is backed by industry-standard validations. From fiber optical transceiver manufacturing to final visual inspection, from IQC、IPQC、FQC to OQC, our processes ensure global compliance and reliability.

We adhere to rigorous standards for our SFP modules and network solutions:

  • ISO 9001: Certified quality management and production consistency.

  • CE & FCC: Fully compliant for seamless Global Market Access.

  • RoHS: Committed to environmental responsibility and hazardous material control.

  • Proven Reliability: Rigorous testing to reduce compliance risk and ensure safety.

Certified Quality. Global Standards. Guaranteed Performance.




Rigorous Industrial Product Testing



100% 3rd Party Compatible

Partial Test Demonstration
