Ciena XCVR-B00CRJ Compatible 10/100/1000BASE-T SFP SGMII 100m RJ-45 Copper SFP Module | HYTOPTODEVICE

Source Ciena XCVR-B00CRJ compatible copper SFP module directly from HYTOPTODEVICE factory. This triple-speed 10/100/1000BASE-T SFP SGMII RJ45 copper transceiver supports 100m Cat5e/Cat6 links for Ciena carrier edge platforms. Bulk wholesale, sample evaluation, low MOQ for copper SFP module buyers and network integrators.
NO. Brand  Compatible P/N Transceiver Type
1 Cisco  GLC-TA SFP-GE-T
2 Alcatel-Lucent  iSFP-GIG-T SFP-GIG-T
3 Brocade  E1MGTX-A GLC-TE-I
4 Extreme 10065 SFP-10G-T-30
5 Juniper Networks EX-SFP-1GE-T SFP-10G-T-30I
6 MikroTik  S-RJ01  SFP-10G-T-80
7 Ciena XCVR-B00CRJ SFP-10G-T-100
8 Finisar  FCLF8522P2BTL
Description

Ciena XCVR-B00CRJ Compatible 10/100/1000BASE-T SFP SGMII 100m RJ-45 Copper SFP Module | HYTOPTODEVICE


Product Overview

HYTOPTODEVICE Ciena XCVR-B00CRJ compatible copper SFP module delivers flexible triple-speed 10/100/1000BASE-T Ethernet transmission over twisted-pair copper cabling. This hot-swappable SFP copper module with RJ45 connector supports up to 100-meter links over Cat5e/Cat6 cable and uses SGMII host interface for seamless communication with Ciena edge networking platforms. Built to IEEE 802.3 & SFP MSA standards, pre-programmed EEPROM enables plug-and-play recognition under Ciena SAOS without unsupported transceiver warning logs. This copper SFP module supports auto-negotiation for 10Mbps,100Mbps and 1000Mbps speeds. HYTOPTODEVICE manufactures this copper SFP module for network distributors, system integrators and bulk purchasers.

Key Technical Specifications

   Ciena  Compatible XCVR-B00CRJ Vendor Name HYTOPTODEVICE
Form Factor SFP  Data Rate 10/100/1000Mbps
Connector RJ-45 Cable Distance 100m
Media Copper Cable Type Cat 5e/6/6a (UTP)
Max. Power Consumption ≤1.2W DDM Support YES
Protocols MSA Compliant, IEEE STD 802.3 and 802.3ab Operation Temperature 0 to 70°C (32 to 158°F)

  For detailed technical specifications, please refer to the Datasheet


Usage Guidelines & Best Practices

1. Cabling Requirement

  • Standard: Cat5e or Cat6 twisted-pair cable is required to achieve full 100-meter Gigabit performance.

  • Note: Standard Cat5 cable may limit link stability at full 1G speed and is not recommended.

2. Hot-Plug Support

  • Live Insertion: The SFP RJ45 transceiver supports live insertion and removal.

  • Precaution: Avoid repeated hot swapping under continuous heavy traffic loads to ensure optimal hardware longevity.

3. Thermal Management

  • Heat Dissipation: This 1Gbps copper module generates mild heat during operation.

  • Deployment Advice: Verify the switch thermal budget and ensure adequate ventilation before fully populating all SFP ports.

4. Speed Limitation

  • Fixed Rate: This RJ45 transceiver operates at a fixed 1000Mbps speed only.

  • Compatibility Warning: It cannot auto-negotiate down to 100Mbps or 10Mbps. The connected peer device must support 1G speed to successfully establish a link.

5. Storage & Maintenance

  • Storage Environment: Keep unused transceivers stored in dry, ESD-safe packaging.

  • Dust Protection: Always fit dust caps onto the RJ45 port when the module is not in service.

For detailed operation instructions, please refer to the User Guide.

Full Compatibility List & Firmware Adaptation

1. Validated Target Hardware & Firmware

This 10/100/1000BASE-T copper SFP module uses XCVR-B00CRJ matched EEPROM coding for seamless plug-and-play detection without transceiver warning alerts. Every unit passes hardware validation and burn-in testing before factory shipment:
  • Ciena Edge Platforms: 3903, 3903x, 3922, 3924, 3984
  • Ciena Aggregation Routers: 5132, 5166
  • Any Ciena hardware fitted with standard SFP SGMII ports supporting 10/100/1000BASE-T
 Important note: This copper SFP module supports auto-negotiation 10/100/1000Mbps triple speed.

2. Multi‑Brand Cross Interoperability

Built on SFP MSA and IEEE industry standards, this RJ45 SFP Transceiver module also works with Fortinet, Dell, Extreme and other mainstream network hardware, suitable for mixed-brand enterprise and campus network renovation projects.

3.Value-Added Services

HYTOPTODEVICE provides free custom EEPROM programming, pre-sales technical consultation, test sample support, custom labeling and packaging services for wholesalers, integrators and bulk buyers working on 1000BASE-T SFP copper deployments.


Primary Application Scenarios

  • Enterprise wiring closet triple-speed LAN connections with RJ45 transceiver
  • Rack to rack short-distance 10/100/1000BASE-T RJ45 transceiver uplink deployment
  • Switch to server NIC short copper patch links
  • Legacy Cisco network upgrades converting SFP SGMII slots to RJ45 ports
  • Office LAN, IP camera and VoIP phone links requiring flexible speed auto-negotiation

Connectivity Solutions(Applications)

1. 1G to 1G for Switch-Switch

2.1G Connectivity with Switch-NIC


3.1G Structured Cabling Connectivity



The Core Features

1.Low power design for reliable 1G copper connectivity.

These low-power RJ45 SFP transceivers deliver stable 1G copper connectivity, perfectly suited for Gigabit Ethernet deployments in data centers.
1000BASE-T SFP transceiver, low power, 1G copper connectivity for data center Gigabit Ethernet networking


2.Tested in Host Devices for Proven Interoperability

Every RJ-45 copper SFP transceiver module passes interoperability validation on target switch firmware, offering plug-and-play operation with no unrecognized transceiver alert messages. Specific Compatibility Video available upon request.

1000BASE-T SFP transceiver, fully tested on host devices for proven interoperability with mainstream network hosts

3.Comprehensive quality management and inspection

Each RJ45 SFP Transceiver Module must go through burn-in cycle and full functional verification before factory shipment, guaranteeing reliable performance for H3C enterprise network rollout and campus network refresh projects.Curious how? Tour the Test Center.
000BASE-T SFP transceiver with comprehensive quality management and multi-stage inspection for reliable performance


FAQ

Q1: Can this copper SFP module auto negotiate 10M,100M and 1000M speeds for mixed end devices?

A: Yes, this copper SFP module supports 10/100/1000BASE-T auto-negotiation. HYTOPTODEVICE Ciena XCVR-B00CRJ compatible copper SFP module automatically synchronizes speed with connected peer devices over Cat5e/Cat6 cabling, perfect for mixed-speed LAN environments mixing gigabit and fast ethernet hardware at carrier edge sites.

Q2: Does my Ciena edge device need SGMII interface to run this copper SFP module?

A: Yes, host hardware must carry SGMII interface to operate this copper SFP module properly. This Ciena compatible copper SFP module relies on SGMII to transfer signals between device PHY and copper transceiver, it cannot function if SFP port only supports 1000BASE-X without SGMII.

Q3: What cable types can reach full 100m transmission distance with this copper SFP module?

A: Cat5e or Cat6 twisted pair cables are required for full 100m reach of this copper SFP module. HYTOPTODEVICE copper SFP module follows IEEE 802.3 standard, and older Cat5 cable may cause signal attenuation, crosstalk and unstable link when running near maximum distance. Cat6 / Cat6a is recommended: it provides larger margin and superior anti-interference performance, and supports future network upgrades to 2.5G/10G (Cat6 supports 2.5G/5G, Cat6a supports 10G).

Q4: Can this copper SFP module build links between network hardware from different vendors?

A: Yes, this copper SFP module supports multi-brand interoperability based on IEEE and SFP MSA standards. HYTOPTODEVICE Ciena XCVR-B00CRJ compatible copper SFP module can connect cross-brand switches and edge routers as long as both sides equip SGMII SFP ports and support 10/100/1000BASE-T.

Q5: Does this copper SFP module have built-in MDI/MDIX auto crossover capability?

A: Yes, auto MDI/MDIX crossover function is integrated inside this copper SFP module. You can directly use straight-through patch cables without crossover cables for device-to-device or device-to-server connections, simplifying on-site cabling work for installers deploying HYTOPTODEVICE copper SFP module.

Q6: What is the typical power consumption when installing multiple copper SFP module in high-density Ciena edge platforms?

A: Each copper SFP module consumes typical ~1.05W power. Low power design reduces heat accumulation for high-density SFP port arrays. You can easily calculate total power budget when deploying multiple HYTOPTODEVICE copper SFP module filling all available SFP slots.

Q7: Can this copper SFP module connect IP cameras and VoIP phones inside carrier or enterprise local area networks?

A: Yes, this copper SFP module works reliably for IP camera and VoIP phone LAN links. The triple-speed auto-negotiation adapts to 100Mbps for older cameras and 1Gbps for newer devices. HYTOPTODEVICE copper SFP module converts SFP SGMII port to standard RJ45 port to connect these end devices.

Q8: Does this copper SFP module include DDM digital diagnostic monitoring to read real-time operational parameters?

A: No, this copper SFP module does not support DDM/DOM monitoring functions. Unlike optical transceivers, this RJ45 copper SFP module has no optical power monitoring. You can check link status directly on the Ciena device web management page after installing HYTOPTODEVICE copper SFP module.

Q9: What is the difference between this triple-speed copper SFP module and single-speed 1000BASE-T copper SFP module?

A: This copper SFP module supports 10/100/1000 auto negotiation, while fixed 1000BASE-T copper SFP module only runs at gigabit speed. HYTOPTODEVICE Ciena XCVR-B00CRJ compatible copper SFP module is suitable for mixed-speed LAN where many endpoints only support 100Mbps Fast Ethernet.

Q10: Can I hot swap this copper SFP module while the Ciena edge device stays powered and online?

A: Yes, this copper SFP module supports hot swap defined by SFP MSA specification. You can insert or remove HYTOPTODEVICE copper SFP module without powering down the host hardware. Frequent repeated hot-plugging should be avoided to reduce mechanical wear on the SFP connector.

Q11: Will temperature and humidity variations inside ceiling plenum areas affect links using this copper SFP module?

A: Within rated 0~70°C operating range, this copper SFP module maintains stable links. Extreme high humidity and temperature swings mainly degrade copper cable performance rather than the transceiver itself. Use plenum-rated Cat5e/Cat6 cables and maintain adequate ventilation for HYTOPTODEVICE copper SFP module deployments inside ceiling spaces.

Q12: Will 802.1X port-based network access control work normally on ports fitted with this copper SFP module?

A: Yes, 802.1X authentication works normally with this copper SFP module. Authentication logic runs on host Ciena device firmware, and HYTOPTODEVICE copper SFP module only forwards Ethernet frames without interfering security traffic. You can apply port-based network access policies normally.

Q13: What happens if the power supply fails on a Ciena platform populated with this copper SFP module?

A: Without redundant power supply, the whole device will power off and drop all links using this copper SFP module. Deploy dual power supplies for critical carrier and enterprise LAN segments. HYTOPTODEVICE copper SFP module itself does not provide power backup function.

Q14: Can network monitoring tools capture port-mirrored traffic over links equipped with this copper SFP module?

A: Yes, port mirroring functions normally on links fitted with this copper SFP module. The HYTOPTODEVICE copper SFP module forwards mirrored Ethernet packets without modification. Network technicians can connect packet analyzers to monitor traffic for troubleshooting and network audit.

Q15: Can HYTOPTODEVICE customise EEPROM coding of this copper SFP module for my Ciena hardware?

A: Yes, HYTOPTODEVICE provides free custom EEPROM programming service for this copper SFP module. We can customise EEPROM data to match Ciena XCVR-B00CRJ identity and eliminate transceiver warning logs on your target network hardware for bulk orders.
