| NO. | Brand | Compatible P/N | Transceiver Type |
| 1 | DELL | 430-4593 | QSFP-40G-SR4(Cisco) |
| 2 | EdgeCore | ET6401-SR4 | QSFP-40G-SR4(Huawei) |
| 3 | Extreme | 10319 | QSFP-40G-IR4 |
| 4 | HPE Aruba | JH231A | QSFP-40G-LG4 |
| 5 | H3C | QSFP-40G-SR4-MM850 | QSFP-40G-ER4 |
| 6 | HPE BladeSystem | 720187-B21 | QSFP-40G-ZR4 |
| 7 | HPE H3C | JG325A | QSFP-40G-CSR4 |
| 8 | F5 Networks | F5-UPG-QSFP+ |
| Extreme Compatible | 10319 | Vendor Name | HYTOPTODEVICE |
| Form Factor | QSFP+ | Max Data Rate | 41.25Gbps |
| Wavelength | 850nm | Max Distance | 150m@OM4/100m@OM3 |
| Connector | MTP/MPO | Transmitter Type | VCSEL 850nm |
| Cable Type | MMF | Receiver Type | PIN |
| TX Power | -8.0~1.0dBm | Receiver Sensitivity | < -13dBm |
| Power Consumption | ≤1.5W | Modulation | NRZ |
| Protocols | IEEE 802.3 40GBASE-SR4, SFF-8436 | Operation Temperature | 0 to 70°C (32 to 158°F) |
Usage Guidelines & Best Practices
Fiber Choice: Only compatible with OM3 / OM4 multi‑mode MPO‑12 trunk cabling; single‑mode fiber cannot facilitate 850 nm SR4 operation and will produce link failure.
Distance Limit: 100‑metre maximum operating reach on OM3, 150‑metre maximum on OM4; excessive splice joints, dirty connector end‑faces or sharp fiber bends degrade practical transmission distances.
Cleanliness & Dust: Keep dust caps on whenever unattached. Clean fiber end-faces with a optical cleaning pen before insertion; dust causes over 80% of optical link failures.
Installation Specification: Hot‑plug supported; keep MPO connector end‑faces clean, observe minimum fiber‑bend radius requirements.
Operating Environment: Designed for commercial‑grade 0°C‑70°C ambient conditions; maintain adequate cabinet‑level airflow to prevent excessive module temperature build‑up.
Full Compatibility List and Supported Devices
1. Supported Hardware & Firmware
Primary Application Scenarios
• Intra‑data‑center short‑haul leaf‑spine fabric connections built with EdgeCore SONiC‑capable open switches
• 40G aggregation‑layer trunk bandwidth expansion for open‑compute enterprise campus infrastructures
• Top‑of‑Rack 40G uplink pathways linking EdgeCore ToR hardware to virtualisation and HPC server farms
• Rack‑to‑rack short‑distance multi‑mode fiber connections within open‑compute server halls
• Enterprise and service‑provider infrastructure modernisation projects based on EdgeCore open‑networking hardware
• Multi‑vendor mixed‑fabric deployments supporting cloud‑native and container‑based workload environments
1. 40G Connectivity for Data Center
High speed, low overhead. The QSFP+ 40G optical transceiver brings gigabit-class throughput to dense data center racks while drawing less power and taking up less space.
FAQ
Q1: How do I clear unsupported‑transceiver warnings after fitting HYTOPTODEVICE QSFP+ 40G SR4 on Extreme Summit switches? A: This usually means the module's coding does not match the switch's vendor lock. Genuine‑compatible HYTOPTODEVICE modules include the right coding; if the message persists, check the port configuration, update firmware, or contact us for a recode.
Q2: Can HYTOPTODEVICE 40G SR4 work alongside existing 10G SFP+ hardware for phased Extreme network modernisation? A: Yes, with a breakout solution: the 40G SR4 can be split into 4×10G links using an MPO‑to‑4×LC breakout cable connected to SFP+ ports, letting you migrate gradually.
Q3: What fiber types are required to operate HYTOPTODEVICE Extreme‑compatible QSFP+ 40G SR4 modules? A: Multimode fiber only — OM3 or OM4 (OM5 also supported on some platforms). It will not work on single‑mode fiber; that requires a 40G LR4 module.
Q4: What typical power draw should planners account for when populating dense Extreme switch racks with HYTOPTODEVICE QSFP+ 40G SR4? A: Typically around 1.0–1.5 W per module, depending on vendor and temperature — far lower than the MSA maximum, so it is safe for dense switch line cards.
Q5: What insertion loss and link‑budget values need evaluation for HYTOPTODEVICE 40G SR4 inside Extreme‑managed fiber plant? A: The 40GBASE‑SR4 channel supports a maximum insertion loss of about 1.9 dB (including connectors and patch panels). Confirm your cable plant loss before deployment.
Q6: Will deploying HYTOPTODEVICE 40G SR4 hardware constrain future 100G upgrade plans on Extreme infrastructures? A: It is a 40G product; the fiber (OM3/OM4) can often be reused for 100G SR4/SR10, but the module and ports must be upgraded. Plan cabling with future capacity in mind.
Q7: Can existing on‑site MPO trunk cabling be reused with HYTOPTODEVICE QSFP+ 40G SR4 in Extreme network projects? A: Check the fiber count, connector polish (UPC), and polarity. Existing 12‑fiber MPO trunks are often reusable, but verify loss and polarity against SR4 requirements.
Q8: What performance trade‑offs arise when mixing OM3 and OM4 multimode fiber within one physical link using HYTOPTODEVICE 40G SR4? A: Yes, but the reach is limited by the shorter‑grade segment (OM3), so a mixed link is rated at 100 m maximum.
Q9: What compliance certificates are available for HYTOPTODEVICE factory‑bulk‑ordered QSFP+ 40G SR4 transceivers? A: Typical certifications include CE, FCC, RoHS, and REACH compliance; some suppliers also hold ISO 9001. Ask for certificates before ordering.
Q10: Are HYTOPTODEVICE QSFP+ 40G SR4 units properly ESD‑shielded for shipping and on‑site handling within Extreme deployments? A: Yes — they ship in anti‑static packaging and are designed for hot‑swap with ESD protection. Always ground yourself before handling.
Q11: What stock position and expected lead‑time apply for HYTOPTODEVICE Extreme‑compatible QSFP+ 40G SR4 factory bulk orders? A: Popular models (Cisco/Arista/Juniper‑compatible 40G SR4) are usually in stock with 24–72 h dispatch; custom‑coded or industrial versions may take 1–3 weeks.
Q12: Which payment options and international Incoterm arrangements can HYTOPTODEVICE support for cross‑border factory wholesale QSFP+ 40G SR4 procurement? A: Typical terms: T/T, PayPal, or trade assurance for smaller orders; FOB, CIF, or DDP for freight. Confirm total landed cost (shipping, duties, taxes) before finalizing.
Q13: Are there unplanned import‑related hidden fees when importing HYTOPTODEVICE QSFP+ 40G SR4 for Extreme enterprise projects overseas? A: Duties and taxes vary by destination and Incoterm. Ask the supplier to quote DDP if you want a fixed, all‑inclusive delivered price with no surprises at customs.
Q14: How can ExtremeXOS administrators retrieve real‑time optical diagnostic metrics from HYTOPTODEVICE QSFP+ 40G SR4? A: Use the switch CLI (e.g., show interface transceiver or show optics) to view per‑lane temperature, voltage, TX/RX power, and alarms — the data comes from the module's standard DOM.
Q15: Does investing in 40G SR4 still deliver tangible business value amid industry transition toward 100G / 400G speeds for Extreme environments? A: For existing 40G networks it remains fully supported and cost‑effective; your multimode cabling can often be reused later. Choose suppliers with long‑term availability so you can restock for years.
Packaging & Custom OEM Solutions
Each QSFP+ SR4 module is individually sealed in ESD-safe anti-static packaging and stocked for same-day dispatch. Bulk orders can also be customized with OEM packaging—logo printing and private labeling included—built for network distributors, system integrators, and enterprise deployments.
