Juniper SFP-1GE-EZX-160 Compatible 1000BASE-EZX Optical Transceiver |1550nm 160km SMF Bulk Wholesale | HYTOPTODEVICE
Product Overview
The Juniper SFP-1GE-EZX-160 compatible SFP from HYTOPTODEVICE is a high-performance, ultra-long-haul optical transceiver engineered for mission-critical Juniper networking environments. Delivering 1000BASE-EZX performance, this module utilizes a high-precision 1550nm cooled DFB laser and a premium APD receiver to achieve a staggering 160km transmission distance over Single-Mode Fiber (SMF). As a leading source factory, HYTOPTODEVICE ensures this module is fully compliant with Junos OS, eliminating "unsupported transceiver" errors. It adheres strictly to SFP MSA, IEEE 802.3z, and SFF-8472 standards, featuring a stable commercial operating temperature range of 0°C to 70°C. With built-in Digital Optical Monitoring (DOM), it provides network administrators with precise real-time data on link health, making it the perfect choice for regional service provider backbones and long-distance metro links.
Key Product Parameters
| Juniper Compatible |
SFP-1GE-EZX-160 |
Vendor Name |
HYTOPTODEVICE |
| Form Factor |
SFP |
Max Data Rate |
1.25Gbps |
| Wavelength |
1550nm |
Max Distance |
160km |
| Connector |
Duplex LC |
Transmitter Type |
DFB 1550nm |
| Cable Type |
SMF |
Receiver Type |
APD |
| TX Power |
1~6dBm |
Receiver Sensitivity |
< -36.0dBm |
| Typical Power Consumption |
≤1W |
Receiver Overload |
-8dBm |
| Bit Error Ratio (BER) |
1E-12 |
DDM/DOM |
Support |
| Protocols |
SFF-8472 MSA Compliant, IEEE 802.3ah-2004 |
Operation Temperature |
0to 70°C (32 to 158°F) |
Usage Guidelines & Laser Safety
Always wear an ESD wristband when handling this 160km Juniper SFP-1GE-EZX-160 compatible sfp transceiver, and never look directly into powered optical ports to avoid permanent eye damage. Before connecting the fiber to the RX port of this long haul sfp transceiver, always measure the input power with an optical power meter; for short spans under 20km or loopback testing, you must install a 10dB–20dB fixed optical attenuator to prevent burning out the highly sensitive APD receiver inside the gigabit sfp transceiver. Keep dust caps on when the module is idle, and clean all fiber connectors and ports before insertion to prevent extra signal loss of the ultra long reach sfp transceiver. Lastly, ensure host device ventilation to handle the higher heat output of the 160km sfp transceiver, and regularly monitor DDM metrics (power, temperature) via NMS to ensure stable long-distance transmission operation.
When the long-reach sfp optical transceiver is used in short distance transmission, please match it with the appropriate attenuator according to the table.
| Distance |
≤ 5km |
≤ 25km |
≤ 45km |
≤ 65km |
| Attenuator |
20dB |
15dB |
10dB |
5dB |
Links to the Datasheet, User Guide and Compatibility Guides are available on the product page.Full Compatibility List & Supported Network Hardware
1. Native Juniper Networks Compatibility
This Juniper SFP-1GE-EZX-160 compatible sfp transceiver is preloaded with Juniper-matched EEPROM firmware at factory, delivering native plug-and-play recognition, zero error alarms and full DOM data display on all mainstream Juniper switching, routing and aggregation devices. No manual command unlocking or configuration changes required for carrier-grade stable long-haul backbone deployment.Compatible Juniper Device Models:
- Juniper EX2200 / EX3400 / EX4300 / EX4600 Series Switches
- Juniper QFX5100 / QFX5120 / QFX5200 Series Switches
- Juniper MX80 / MX104 / MX240 / MX480 / MX960 Universal Routers
- Juniper SRX340 / SRX380 / SRX550 / SRX650 Security Gateways
- Juniper Legacy M7i / M10i / M120 Series Routers
2.Multi-Brand Cross Compatibility
This MSA-compliant sfp transceiver supports universal cross-brand adaptation for open-brand and locked-brand network hardware. Open-brand equipment works plug-and-play with factory default settings; locked-brand devices require customized EEPROM firmware to bypass vendor authentication for alarm-free full-function operation.
- Open-Brand Compatibility: MikroTik, Ubiquiti, TP-Link, D-Link, Zyxel, Fortinet, Ruijie and other universal SFP-port network devices
- Locked-Brand Compatibility: Cisco, Arista, Juniper, H3C, Huawei, HP/Aruba, Dell, Brocade, Intel and other vendor-locked switch/router platforms (custom firmware required)
3. Free Custom EEPROM Re-Flash Service
We provide free EEPROM re-flash and firmware customization for bulk orders of this sfp transceiver. Our team edits vendor ID, private model names and DOM display data to eliminate vendor lock, tailored for global importers and distributors. We support bulk wholesale, private label printing and OEM/ODM custom configuration for system integrators worldwide.
Primary Application Scenarios
This Juniper SFP-1GE-EZX-160 compatible sfp transceiver targets ultra-long-distance single-mode fiber transmission, widely deployed in core long-haul networking scenarios:
- Inter-City Telecom Backbone Transmission: Connect cross-city communication core nodes with 160km long-distance fiber links
- Cross-Regional Enterprise Private Line Networking: Build stable gigabit dedicated links connecting headquarters and remote branch campuses over long fiber spans
- Remote Industrial & Mining Park Interconnection: Adapt to outdoor long-distance fiber laying for isolated industrial site data backhaul
- Rural Broadband Long-Distance Access: Extend fiber coverage to remote villages far away from central computer rooms
- Long-Haul Wireless Base Station Backhaul: Transmit gigabit data signals for remote 4G/5G base station CPRI backhaul links
Connectivity Solutions(Applications)
1.Point-to-Point Long-Haul Backbone Link

2.Remote Terminal Access Link
3.Enterprise Integrated Structured Cabling System

The Core Feature
1. Low-Power, Cost-Effective Long-Haul Connectivity
Featuring low power consumption and high cost-efficiency, it is the ideal choice for expanding your Gigabit Ethernet coverage.
2.Host-Tested for Proven Interoperability
All transceiver modules pass real
device testing. Pre-flashed EEPROM ensures zero-alarm recognition, fixing third-party module incompatibility and link flapping for safe bulk purchase.Specific Compatibility Video available upon request.
3.100% Tested for Zero-Defect Reliability
Step inside our
Test Center to see every transceiver module is 100% tested before shipment, ensuring zero-defect reliability and maximum uptime for your network.

FAQ
Q1: How does HYTOPTODEVICE ensure compatibility with Junos OS?
A: Our engineering team uses the latest Juniper-specific EEPROM signatures. The SFP-1GE-EZX-160 will be identified by Junos as an "Optical Transceiver" with all vendor information correctly displayed in the show chassis hardware command.
Q2: Can I use this 160km module for a 20km link?
A: You can, but only with a fixed optical attenuator (typically 20dB). Because this is an EZX ultra-long-reach module, the laser power will overwhelm and potentially "burn" the receiver if used over short distances without attenuation.
Q3: What makes the HYTOPTODEVICE "Source Factory" version better?
A: By buying from HYTOPTODEVICE, you get the same internal components (laser/chipset) as Tier-1 brands but without the "brand tax," backed by direct factory technical support and rigorous QC.
Q4: Does this module support hot-swapping?
A: Yes, the HYTOPTODEVICE SFP-1GE-EZX-160 is hot-pluggable. You can insert or remove the module without powering down your Juniper switch or router.
Q5: What is the warranty for these long-range modules?
A: We offer a standard 3-year warranty (up to 5 years for project partners) because we trust the stability of our 1550nm EZX laser technology.
Q6: Can HYTOPTODEVICE 160km SFP-1GE-EZX-160 sfp transceiver reach full 160km range on standard G.652 single mode fiber?
A: The 160km rating of our Juniper compatible sfp transceiver is a nominal value calculated based on standard 0.19–0.20 dB/km fiber attenuation. Full 160km stable transmission cannot be guaranteed under all conditions. Poor fiber quality and excessive splicing loss will shorten actual reach; on-site link budget calculation is required before deployment.
Q7: What minimum link budget is necessary for stable 160km long-haul links using EZX sfp transceiver?
A: To maintain error-free transmission and reserve safety margin, this 160km sfp transceiver requires a minimum 34dB–36dB link budget. Its 0~+5 dBm transmit power and -30~-32 dBm receiving sensitivity fully offset fiber attenuation and passive device loss for reliable 160km operation.
Q8: Is an optical attenuator mandatory for short-distance bench testing of 160km EZX sfp transceiver?
A: Yes, attenuators are non-negotiable for short-range testing of this ultra-long-reach sfp transceiver. Direct back-to-back connection without a 15–20dB attenuator delivers excessive optical power that will permanently damage the high-sensitivity APD receiver inside the module.
Q9: How much optical power safety margin should be reserved to cope with long-term fiber aging on 160km links?
A: We recommend reserving a 3dB–5dB optical power safety margin for networks deployed with our 160km sfp transceiver. This buffer counteracts signal attenuation caused by fiber aging, later maintenance repairs and outdoor environmental changes to sustain long-term zero-error transmission.
Q10: What laser chip is built into HYTOPTODEVICE SFP-1GE-EZX-160 sfp transceiver and why it matters for 160km transmission?
A: Our 160km sfp transceiver adopts dedicated DFB/DFB-EA laser chips designed for ultra-long haul. Conventional FP lasers feature wide spectral width and severe dispersion distortion over 160km, while narrow-spectrum DFB lasers stabilize wavelength and eliminate signal distortion for consistent long-distance performance.
Q11: Why does Juniper switch pop up "Unknown Transceiver Type" alert while the fiber link stays online?
A: This alert occurs when the Juniper system fails to identify the custom vendor ID stored in the module’s DOM/DDM EEPROM. Our SFP-1GE-EZX-160 sfp transceiver retains full physical layer compatibility and normal data forwarding, so the link remains active despite the unrecognized vendor prompt.
Q12: Why does the network management system generate false Rx power alarms on 160km EZX long-haul links?
A: False Rx power alarms stem from overly strict threshold values pre-programmed in the sfp transceiver’s EEPROM. When receiving power runs close to the module’s -30dBm critical sensitivity threshold, the NMS triggers warning logs even without actual link faults.
Q13: What performance risks will appear if commercial-grade 160km sfp transceiver operates above 75℃ ambient temperature?
A: Once the ambient temperature exceeds 75℃, this commercial sfp transceiver suffers laser wavelength drift, reduced transmit power and sharply elevated bit error rate. Sustained overheating leads to continuous packet loss and complete long-haul link breakdown.
Q14: How frequently should technicians clean fiber end faces for 160km ultra-long fiber links using high-power sfp transceiver?
A: Every time fiber connectors are detached and reconnected, end faces must be thoroughly cleaned. Tiny dust particles will be permanently fused onto the module lens by the high optical power of this 160km sfp transceiver, causing permanent signal attenuation and unstable links.
Q15: Why are 160km EZX sfp transceivers priced higher than standard 80km ZX gigabit SFP modules?
A: HYTOPTODEVICE 160km ultra-long-reach sfp transceiver uses low-yield high-power DFB lasers, high-sensitivity APD receivers and precise built-in TEC temperature control components. Strict high-precision calibration and multi-stage quality screening for long-haul stability push up manufacturing costs compared to regular 80km medium-reach sfp transceiver models.
Packaging Options & Custom‑Packaging Solutions
Every transceiver module gets reliable ESD‑safe packaging out of the box. Standard packing is ready for immediate shipment, while custom‑printed packaging with your logo is available for bulk orders.

Why Network Engineers Choose HYTOPTODEVICE
HYTOPTODEVICE has supplied over 5000,000 optical transceiver modules to data centers, ISPs, and enterprise networks across 100+ countries since 2011. Every module undergoes a 72-hour burn-in test and full DDM/DOM validation before shipment.
- Up to 70% cost savings vs OEM, transparent pricing & flexible bulk rates, supported quality returns
- 100% real-device compatible with Cisco, Huawei,Dell,Juniper, and Arista
- ISO 9001:2015 Shenzhen factory, full lineup: 1.25G/10G/25G/40G/100G/200G/400G/800G/1.6T transceivers
- Ample stock, fast global DHL/FedEx shipping in 3–5 working days
- Free pre-sales engineering support for custom EEPROM & private label firmware
- Real switch test videos available for pre-purchase review; inspection & shipping videos provided per order
“Phenomenal performance. We deployed 200 HYTOPTODEVICE SFP modules to replace Cisco OEMs in our backbone network. Result? Zero compatibility issues and a 60% reduction in costs. Highly recommended for mission-critical networks."— Senior Network Engineer, Regional Telecom, Australia
Quality Certification & Compliance
At HYTOPTODEVICE, our quality commitment is backed by industry-standard validations. From fiber optical transceiver manufacturing to final visual inspection, from IQC、IPQC、FQC to OQC, our processes ensure global compliance and reliability.
We adhere to rigorous standards for our SFP modules and network solutions:
-
ISO 9001: Certified quality management and production consistency.
-
CE & FCC: Fully compliant for seamless Global Market Access.
-
RoHS: Committed to environmental responsibility and hazardous material control.
-
Proven Reliability: Rigorous testing to reduce compliance risk and ensure safety.
Certified Quality. Global Standards. Guaranteed Performance.

Rigorous Industrial Product Testing

100% 3rd Party Compatible

Partial Test Demonstration
