| NO. | Brand | Compatible P/N | Remarks |
| 1 | Cisco | QDD-4X100G-LR-S | |
| 2 | Arista | QDD-400G-PLR4 | |
| 3 | Dell | 400G-Q56-DD-LDR4 | |
| 4 | HPE Aruba | S3N94A | |
| 5 | Juniper | QDD-4X100G-LR | |
| 6 | Extreme | 400G-LR4P-QSFPDD10KM | |
| 7 | H3C | 400GBASE-PLR4 |
Key Technical Specifications
| Extreme Compatible | 400G-LR4P-QSFPDD10KM | Vendor Name | HYTOPTODEVICE |
| Form Factor | QSFP-DD | Max Data Rate | 425Gbps |
| Wavelength | 1310nm | Max Distance | 10km |
| Modulation Format | PAM4 | Host Required | FEC |
| Connector | MPO-12/APC | Voltage Supply | 3.3V |
| Cable Type | SMF | DDM Support | Yes |
| Transmitter Type | EML | Receiver Type | PIN |
| TX Power | -1.4~+4.5dBm | Receiver Sensitivity | < -9.1dBm |
| Operation Temperature | 0 to 70°C (32 to 158°F) | Maximum Power | < 12W |
| Protocols | QSFP-DD MSA HW Rev 5.1, QSFP-DD, CMIS Rev 5.0, | Application | 400G Ethernet, Data Center Interconnect, Infiniband Interconnects |
| IEEE 802.3cu, IEEE 802.3bs |
