| NO. | Brand | Compatible P/N | Remarks |
| 1 | Cisco | GLC-T | |
| 2 | Alcatel-Lucent | SFP-GIG-T | |
| 3 | Aruba | SFP-TX | |
| 4 | Avaya | 700283872 | |
| 5 | Brocade | E1MG-TX | |
| 6 | Cisco Meraki | MA-SFP-1GB-TX | |
| 7 | D-link | DGS-712 | |
| 8 | DELL | 310-7225 | |
| 9 | Extreme | MGBIC-02 | |
| 10 | F5 Networks | F5-UPG-SFPC-R | |
| 11 | Fortinet | FN-TRAN-GC | |
| 12 | H3C | SFP-GE-T | |
| 13 | HPE BladeSystem | 453154-B21 | |
| 14 | HPE | JD089A | |
| 15 | HPE Procurve | J8177B | |
| 16 | Huawei | SFP-1000BaseT | |
| 17 | IBM | 00FE333 | |
| 18 | Juniper Networks | JX-SFP-1GE-T | |
| 19 | Netgear | AGM734 | |
| 20 | Nortel | AA1419043-E6 | |
| 21 | Palo Alto Networks | PAN-SFP-CG | |
| 22 | Ruijie | MINI-GBIC-GT | |
| 23 | SMC | 1GSFP-T |
The HYTOPTODEVICE F5-UPG-SFPC-R transceiver is rigorously tested to ensure 100% compatibility with F5 BIG-IP systems:
BIG-IP iSeries Platforms: i2000, i4000, i5000, i7000, i10000, and i11000 series.
BIG-IP rSeries Platforms: r2000, r4000, r5000, and r10000 series next-gen appliances.
VIPRION Chassis: Compatible with SFP slots on B2250 and B4450 blades.
VELOS Chassis: Supports control plane and management ports on CX410 and BX110 blades.
Out-of-Band Management (OOBM): Connecting the management port of an F5 appliance to a copper-based management switch.
Legacy Network Integration: Linking high-performance F5 ADC units to existing 1G copper infrastructure in the data center.
Short-Range Interconnects: Facilitating 1G RJ45 connections between F5 devices and nearby servers or firewalls within 100 meters.
Tri-Rate Field Flexibility: Utilizing the tri-rate copper SFP transceiver capability to interface with equipment operating at 10Mbps or 100Mbps
| F5 Networks Compatible | F5-UPG-SFPC-R | Vendor Name | HYTOPTODEVICE |
| Form Factor | SFP | Data Rate | 1000Mbps |
| Cable Type | Cat 5e/6/6a (UTP) | Max Distance | 100m |
| Interface | RJ-45 | DDM Support | No |
| Protocols | MSA Compliant, IEEE STD 802.3 and 802.3ab | Operation Temperature | 0 to 70°C (32 to 158°F) |
Q1: Does the F5-UPG-SFPC-R support 10G speeds? A: No. This F5-UPG-SFPC-R is a 1000BASE-T copper transceiver,not 10GBASE-T.
Q2: Will the F5 appliance recognize this module automatically? A: Yes. HYTOPTODEVICE SFP RJ45 modules are pre-programmed with F5-specific EEPROM data. Upon insertion, the F5 TMOS system will identify it as native hardware, and no special commands are required to enable the port.
Q3: Does this module support rate auto-negotiation? A: Absolutely. It supports 10/100/1000Mbps auto-negotiation, allowing it to automatically match the speed and duplex settings of the connected peer device.
Q4: Can the transmission distance of RJ45 module exceed 100 meters? A: It is not recommended.The reliable limit for 1000BASE-T over Cat 5e/6 is 100 meters by IEEE 802.3ab standards. Exceeding the 100 meters may result in packet loss or link instability.
Q5: Does this module generate significant heat? A: Copper SFP modules have a higher power consumption (approx. 1W) compared to optical modules. It will feel warm to the touch during operation; this is normal. Our metal housing is designed for efficient heat dissipation.
Q6: Is this module TAA compliant? A: Yes. Our production processes meet international trade agreement requirements, and TAA-compliant SKUs are available for government and enterprise projects.
Q7: Will using this compatible module void my F5 hardware warranty? A: No. Under the Magnuson-Moss Warranty Act (and similar global laws), manufacturers cannot void your warranty for using high-quality compatible components.
Q8: Does it support Digital Optical Monitoring (DOM)? A: Most RJ-45 SFP modules (including the original F5-UPG-SFPC-R) do not support DOM, as electrical signals do not have optical power levels to measure.
Q9: Is the F5-UPG-SFPC-R hot pluggable? A: Yes. It is a hot-pluggable RJ45 SFP module, hot-pluggable SFP MSA compliant. allowing you to insert or remove the module while the F5 appliance is powered on.
Q10: What is the lead time for HYTOPTODEVICE F5 compatibles? A: As a source-factory, we maintain deep stock for F5-coded materials. HYTOPTODEVICE will service you with ample stock, flexible and fast production. Regular orders usually ship within 48 hours.
Quality Assurance：Your Trusted Optical Transceiver Source
HYTOPTODEVICE is a vertically integrated manufacturer of high-performance optical transceivers. By controlling core materials at the source, we ensure every SFP module meets the highest standards of reliability and customization.
Vertical Integration: In-house core material production ensures a stable, self-sufficient supply chain for all optical modules.
Total Traceability: End-to-end oversight from raw components to final transceiver assembly guarantees 100% controllability.
Bespoke Solutions: Expert-led R&D provides customized SFP transceiver designs tailored to your specific technical needs.
24-Hour Response: Our technical team guarantees a primary response to any inquiry or quality concern within 24 hours.
Carrier-Grade Quality. Factory-Direct Control. Rapid Response.
Quality Certification & Compliance：
At HYTOPTODEVICE, our quality commitment is backed by industry-standard validations. From fiber optical transceiver manufacturing to final inspection, our processes ensure global compliance and reliability.
We adhere to rigorous standards for our SFP modules and network solutions:
ISO 9001: Certified quality management and production consistency.
CE,UL & FCC: Fully compliant for seamless Global Market Access.
RoHS: Committed to environmental responsibility and hazardous material control.
Proven Reliability: Rigorous testing to reduce compliance risk and ensure safety.
Certified Quality. Global Standards. Guaranteed Performance.
