Dell 800G-O112-2VR4 Compatible 800GBASE-2VR4 OSFP 800G SR8 850nm 50m Finned Top PAM4 DOM Dual MPO-12 MMF Optical Transceiver Module-HYTOPTODEVICE

Name: Dell 800G-O112-2VR4 Compatible 800GBASE-2VR4 OSFP 800G SR8 850nm 50m Finned Top PAM4 DOM Dual MPO-12 MMF Optical Transceiver Module-HYTOPTODEVICE
Brand: Shenzhen Hytoptodevice Technology & Service Co.,Ltd
Availability: InStock
Rating: 5 (1 reviews)

Compatible:

NO.	Brand	Compatible P/N	Remarks
1	Cisco	OSFP-800G-VR8
2	NVIDIA/Mellanox	MMA4Z00-NS
3	H3C	OSFP-800G-VR8-MM850-DMPO
4	Arista	OSFP-800G-2SR4
5	Juniper	OSFP-2X400G-VR4-P
6	Dell	800G-O112-2VR4

GET A QUOTE

Description

Product Detail：

HYTOPTODEVICE Dell 800G-O112-2VR4 Compatible 800GBASE-2VR4 SR8 OSFP Finned Top PAM4 850nm 50m Fiber Optical Transceiver Module
The HYTOPTODEVICE 800G-O112-2VR4 is a high-density Dell compatible 800G OSFP optical transceiver designed for next-generation 800G Ethernet, Data Center Interconnect (DCI), and InfiniBand Interconnects. Featuring a "Twin-port" 2xVR4 architecture, this 800g osfp sr8 module provides extreme bandwidth density for modern AI-driven infrastructures. Fully compliant with OSFP MSA and IEEE 802.3ck protocols, it is built with top-tier core chipsets and high-stability 850nm VCSEL lasers to deliver 800Gbps (8x100G PAM4) aggregate throughput. With Finned Top design for optimized thermal dissipation it ensures superior signal integrity over OM4 multimode fiber (MMF) up to 50 meters in commercial operating temperature range (0°C to 70°C),With integrated Digital Optical Monitoring (DOM), HYTOPTODEVICE guarantees 100% interoperability with Dell PowerSwitch Z-Series platforms. Our commitment to a stable long-term supply and rapid delivery makes this the ideal solution for scaling high-performance compute fabrics.

Compatibility and Supported Devices
The HYTOPTODEVICE Dell 800G-O112-2VR4 is precision-coded for 100% seamless integration with:

Dell PowerSwitch Z-Series: Z9664F-ON and other 800G-capable modular switches.
Dell PowerEdge Servers: Equipped with 800G OSFP Network Interface Cards (NICs).
Dell Networking S-Series: High-performance aggregation platforms.
NVIDIA/Mellanox Environments: Tested for cross-platform interoperability in mixed Dell and NVIDIA NDR networking setups.

Primary Application Scenarios

800G Ethernet Networking: Enabling massive spine-to-leaf throughput in Dell-powered hyperscale data centers and enterprise cores.
InfiniBand Interconnects: Supporting low-latency, high-bandwidth NDR connectivity for GPU-to-GPU clusters in AI and Machine Learning environments.
Data Center Interconnect (DCI): Providing cost-effective, very short-reach (VR) 800G links between Dell PowerEdge servers and high-speed switching layers.
Flexible Breakout Solutions: The 2xVR4 design allows for efficient 800G to 2x400G VR4 breakout configurations, facilitating flexible port mapping and hardware migration.

Key Product Parameters

Dell Compatible	800G-O112-2VR4	Vendor Name	HYTOPTODEVICE
Form Factor	OSFP	Max Data Rate	850Gbps(8x 106.25Gbps)
Wavelength	850nm	Max Distance	30m on OM3/50m on OM4
Modulation Format	PAM4	Host Required	FEC
Connector	Dual MTP/MPO-12	Voltage Supply	3.3V
Cable Type	MMF	DDM Support	Yes
Transmitter Type	850nm VCSEL	Receiver Type	PIN
TX Power	-4.6~+4.0dBm	Receiver Sensitivity	< -4.6dBm
Operation Temperature	0 to 70°C (32 to 158°F)	Maximum Power Consumption	< 15W
Protocols	CMIS Rev 5.0, IEEE P802.3ck and IEEE 802.3cu	Application	800G Ethernet, Data Center Interconnect, Infiniband Interconnects

Connectivity Solutions：

Scenarios 4:800G-to-4x 200G Links for Switch-to-Server

FAQ for Dell 800G-O112-2VR4 Compatible OSFP Transceivers

Q1:What is OSFP-800G-SR8? A:The 800G OSFP SR8 is a hot pluggable optical transceiver module with a speed of 800Gbps, a wavelength of 850nm, and a transmission distance of up to 50m with OM4 MMF. It is ideal for data centre, 800G Ethernet and HPC.

Q2:What is the maximum transmission distance of the 800G SR8 transceiver?A:HYTOPTODEVICE OSFP 800G SR8 module supports the maxium transmitting distance of up to 100m with OM4 MMF.

Q3:How is the OSFP 800G SR8 compatibility with OM4 fiber?A:The OSFP-800G-SR8 optical transceiver is fully compatible with OM4 Multimode Fiber (MMF), it has a maximum transmission distance of up to 50 meters with OM4 MMF.

Q4:What is the 800G SR8 vs 400G SR4 transceiver comparison?A:Both the OSFP 800G SR8 and OSFP 400G SR4 are MMF optic modules with a wavelength of 850nm and a transmission distance up to 50m (OM4). The difference is that the 800G SR8 doubles the 800G speed by using eight 100Gbps channels, while the 400G SR4 has a speed of 400Gbps and uses four 100Gbps channels.

Q5:What are the power consumption and cooling requirements for the 800G SR8 modules?A:The power consumption of an 800G SR8 optical transceiver is generally around 8-16W, depending on the specific model.adequate cooling is required to maintain the performance and lifespan of optical transceivers.

Q6:Where to buy 800G OSFP SR8 multimode optical transceiver?A:There are many manufacturers that produce and sell 800G optical modules, but 800g osfp sr8 manufacturer china HYTOPTODEVICE is the ideal provider: a source factory, fully controllable, reliable performance, 100% compatible, sufficient inventory, fast delivery, and rapid response.

Q7:The link is "Up" but I have high packet loss. Why? A:There could be two reasons,1. Dirty connectors:tiny dust particles can obstruct signal transmission. Please use fiber optic cleaner to clean the connector. 2. Fiber optic cable bending: avoid severe bending of the fiber optic cable.

Q8:Is the 800G SR8 backward compatible with lower-speed modules,such as 100G?A:Yes,The 800G SR8 is backward compatible with lower-speed optical transceivers, such as 400G,200G and 100G, but the performance will be reduced.

Q9:How do HYTOPTODEVICE ensure 800G OSFP SR8 module compatibility with network switch?A:Ensuring 100% compatibility, optical modules must be coded to match the switch's requirements. Source-factory HYTOPTODEVICE was equipped with various high-speed switch,the brands include such as Cisco,NVIDIA,Huawei. highly professional in coding equipment for various brands to ensure they are recognized and running in your device.

Q10:Is OSFP-800G-SR8 hot-swappable?A:HYTOPTODEVICE fiber transceivers are hot-pluggable, hot Pluggable OSFP MSA Compliant.you can plug or unplug the optical transceiver, while the device is powered on without damaging the hardware.

Q11:What is OSFP-800G-SR8?A:The 800G OSFP SR8 is a hot pluggable transceiver with a speed of 800Gbps, a wavelength of 850nm, and a transmission distance of up to 100m with OM4 MMF. It is ideal for data centre, 800G Ethernet and HPC.
