Cisco SFP-H25G-CU3M Compatible 25G SFP28 to SFP28 Passive Copper Twinax Cable 3m (10ft) | 25GBASE-CR DAC Bulk Wholesale | HYTOPTODEVICE

HYTOPTODEVICE is a reliable factory supplier for bulk purchase of passive copper twinax cable. This 3m Cisco compatible 25G SFP28 passive copper twinax cable delivers stable 25G transmission, adopts SFP28 form factor, fits mid-range intra-rack cabling and supports Cisco NX-OS / IOS-XE. Buy passive copper twinax cable for Cisco leaf-spine data center deployments.
NO. Brand  Compatible P/N Transceive Type
1 Cisco SFP-H25G-CU3M
2 Arista Networks  CAB-S-S-25G-3M
3 Dell DAC-SFP-25G-3M
4 H3C  SFP-25G-D-CAB-3M
5 Juniper JNP-25G-DAC-3M
6 NVIDIA(Mellanox) MCP2M00-A003
7 HPE Aruba  JL488A
8 HPE  844477-B21
Description

Cisco SFP-H25G-CU3M Compatible 25G SFP28 to SFP28 Passive Copper Twinax Cable 3m (10ft) | 25GBASE-CR DAC Bulk Wholesale | HYTOPTODEVICE

Product Overview

HYTOPTODEVICE 3m passive copper twinax cable serves as direct replacement for Cisco SFP-H25G-CU3M. It follows 25GBASE-CR, SFF-8402 and IEEE 802.3by standards to deliver consistent 25.78125Gbps mid-distance intra-rack links with SFP28 form factor. This passive copper twinax DAC has no built-in electronics, consumes zero power and supports hot swap.
We preload Cisco matched EEPROM signatures to eliminate unnecessary transceiver alerts on NX-OS and IOS-XE. Available for bulk purchase, sample testing and OEM customization for distributors and system integrators.


Key Product Parameters

Cisco Compatible  SFP-H25G-CU3M   Vendor Name HYTOPTODEVICE
Connector SFP28 to SFP28 Max Data Rate 25Gbps
Cable Length 3m (10ft) Wire AWG AWG 26
Cable Type Passive Twinax Power Consumption ≤0.5W
Media Copper Operation Temperature 0~ 70 °C (32 to 158°F)
Jacket Material PVC(OFNR) Protocols IEEE 802.3, SFP28 MSA, SFF-8402, Infiniband, EIA 364-1000
Minimum Bend Radius 21mm Application 25G Ethernet, Data Center, 5G Wireless

For detailed technical specifications, please refer to the Datasheet


Usage Guidelines & Best Practices

  • Mandatory Port Setting: Host SFP28 port must enable 25GBASE mode; link negotiation failure will happen if forced to optical mode.

  • Cabling Requirements: Do not exceed the minimum 21mm bend radius, avoid sharp folding, heavy extrusion or long-term tension on the cable assembly.

  • Port Installation Standard: Works only with standard SFP28  25G ports; cannot be inserted into SFP or XFP slots. Disable the host’s third-party transceiver lock policy in advance if required.

  • Maintenance Specification: Hot‑swap supported, grip the pull tab instead of pulling the cable body during plug/unplug to prevent internal conductor damage.

  • Testing & Storage: Run sample validation on target hardware before large bulk deployment; store spare cables in dry, dust‑free and anti‑static packaging.
  • Operating Environment: This commercial-grade cable operates reliably within 0℃‑70℃; avoid installation beside high-heat power modules.

For detailed operation instructions, please refer to the User Guide.


Full Compatibility List & Supported Devices

1. Validated Cisco Hardware & Firmware

  • Cisco Nexus 93180YC-FX, 93240YC-FX2, 93360YC-FX2 series switches running NX-OS
  • Cisco Catalyst 9300X, 9500X data center switches equipped with SFP28 ports
  • Cisco UCS C220, C240, B200 M5/M6 rack and blade servers with 25G SFP28 NIC

2. Multi-Brand Cross Interoperability

Built on universal MSA open standards, this 25G SFP28 Passive DAC cable can interoperate with mainstream network brands including Arista, H3C, Juniper, Dell, NVIDIA Mellanox and Fortinet, for mixed-vendor rack stacking and server fabric expansion.

3. Free Value-Added Services

  • Custom firmware for multi-device compatibility
  • Support sample testing before bulk orders for project pre-verification
  • Private-label customization and professional deployment guidanc
  • Strict batch consistency quality control
  • Free custom EEPROM programming for special and legacy network environments
  • Free EEPROM rewriting (Tools Included) with 24/7 Tech Support

Primary Application Scenarios
  • Intra-rack leaf-to-server links for Cisco NX-OS leaf-spine fabrics
  • Low-latency NVMe over Fabrics storage cluster interconnections
  • Virtualization hypervisor networking on Cisco UCS server racks
  • HPC cluster node cabling inside deep server cabinets
  • Server backup and synchronous replication networking
  • Direct replacement for original Cisco SFP-H25G-CU3M passive copper twinax cable
  • High-density rack internal switch stacking connections

Connectivity Solutions(Applications)

1. 25G to 25G Direct Link for Switch-Switch
25g sfp28 passive dac cable for switch to switch
2. 25G to 25G Direct Link for Switch-NIC
hytoptodevice 25g sfp28 passive copper twinax cable for switch to NIC
The Core Feature

1. Cost-Effective Ultra-Short Connectivity

Using twinax copper, the 25gb SFP28 Passive Copper Twinax cable replaces a fiber pair and two optical transceivers, significantly cutting interconnect cost for short-reach links — plug-and-play, no modules required.

HYTOPTODEVICE bulk factory wholesale 25G SFP28 DAC cable

2. Ultra-Low Power, Maximum Energy Efficiency

The 25g SFP28 passive copper twinax cable draws lower power consumption, reducing heat and energy costs in dense racks, while delivering a cost-effective, high-speed and low-latency 25G link for short-reach connections — within a rack or across adjacent racks.

bulk factory wholesale 25G SFP28 DAC cable WITH LOW power from hytoptodevice

3.Host-Device Tested for Proven Interoperability

Every SFP28 passive twinax copper cable is rigorously tested for compatibility in the target switch environment, so you can deploy with confidence — no surprises, no downtime. Not sure it fits? Compatibility Video available upon request.

compatible 25g sfp28 direct attach copper cable for data center

4. 100% Individually Tested for Peak Performance

Every single unit is tested individually — no sampling, no shortcuts — to ensure optical compliance and continuous operational stability. Curious how we do it? Take a virtual tour of our Test Center.

HYTOPTODEVICE 25G sfp28  dac cable with comprehensive factory testing stable performance for  platforms bulk wholesale orders


FAQ

Q1: Can this Cisco compatible passive copper twinax cable keep stable full 25G speed on NX-OS? A: Yes, this HYTOPTODEVICE passive copper twinax cable supports full 25.78125Gbps line rate. It is pre-programmed with Cisco EEPROM and validated on NX-OS for reliable 25GBASE-CR links; RS-FEC is optional for 3m deployment.

Q2: What is the maximum reliable transmission distance for this 25G SFP28 passive copper twinax cable? A: The rated maximum reach of 25G SFP28 passive copper twinax cable is 5 meters. This 3m version stays within safe signal loss budget for standard Cisco cabinet routing.

Q3: Can this passive copper twinax cable build cross-vendor links between Cisco Nexus and NVIDIA ConnectX NIC? A: Cross-brand interconnection works reliably with unified 25GBASE-CR and matched FEC configuration. This passive copper twinax cable follows MSA specs for multi-vendor data center fabrics.

Q4: What form factor difference separates SFP28 passive copper twinax cable from older SFP+ DAC? A: SFP28 form factor supports up to 25G signaling while SFP+ only reaches 10G. This passive copper twinax cable uses SFP28 housing to match modern Cisco 25G ports.

Q5: What kind of link failure occurs if this passive copper twinax cable runs over 5 meters? A: 25G twinax copper suffers severe signal attenuation beyond the limit. Length over 5m brings CRC errors and unstable links; longer runs require fiber optical cables.

Q6: Which workloads gain the most latency benefit from this passive copper twinax cable with Cisco Nexus? A: NVMe-oF storage, virtualization and HPC clusters get the biggest performance gain. This HYTOPTODEVICE passive copper twinax cable maintains consistent ultra-low latency.

Q7: Can this 3m passive copper twinax cable be used for direct server-to-server point-to-point connections? A: Direct server interconnection is fully supported after correct port configuration. This passive copper twinax cable works well for data replication inside deep server racks.

Q8: How does AWG wire gauge affect signal performance for a 3m passive copper twinax cable? A: 30AWG balances flexible routing and acceptable signal loss for 3m runs; 26AWG provides better loss margin near the 5m boundary. This cable uses 30AWG twinax optimized for Cisco rack layout.

Q9: Will NX-OS firmware upgrades break identification of this passive copper twinax cable? A: MSA-compliant passive copper twinax cable remains compatible through regular NX-OS updates. Preloaded Cisco EEPROM ensures stable detection on mainstream releases.

Q10: When should AOC fiber replace passive copper twinax cable in Cisco fabric design? A: Choose active optical cables for cross-rack links or distances longer than 5 meters. Passive copper twinax cable is zero-power and cost-effective for intra-rack 25G connections.

Q11: How much latency reduction can passive copper twinax cable achieve versus fiber transceiver links? A: Passive copper twinax cable cuts roughly 30–60ns latency by removing optical-electrical conversion. This improvement is valuable for latency-sensitive storage traffic.

Q12: Can this SFP28 passive copper twinax cable negotiate 25G rate on legacy 10G SFP+ Cisco ports? A: 25G negotiation is impossible on SFP+ ports due to different electrical specifications. Both ends need native SFP28 ports to run this passive copper twinax cable at full speed.

Q13: Can QSFP28 breakout 4×25G DAC replace this SFP28 passive copper twinax cable on Cisco SFP28 ports? A: Breakout DAC uses independent pin mapping and split logic. It cannot substitute this standard point-to-point SFP28 passive copper twinax cable.

Q14: What compatibility tests does HYTOPTODEVICE run on this passive copper twinax cable before shipment? A: Each batch undergoes BER scanning, link-up and hot-swap validation on Cisco Nexus hardware. Testing verifies EEPROM reading and steady 25G signal performance.

Q15: What deployment limits should buyers know before bulk ordering passive copper twinax cable for Cisco fabrics? A: Passive copper twinax cable is designed only for short intra-rack copper connections. It is not suitable for inter-row or long-distance cross-room transmission.


Packaging & Custom OEM Solutions
  • ESD Protection & Fast Shipping: Every transceiver is sealed in an ESD-safe bag and ready for same-day dispatch from stock.

  • Custom OEM & Branding: We provide logo printing, private labeling, and custom packaging to help distributors and integrators build their brand—no factory investment required.


Why Network Engineers Choose HYTOPTODEVICE

HYTOPTODEVICE has supplied over 5000,000 optical transceiver modules to data centers, ISPs, and enterprise networks across 100+ countries since 2011. Every module undergoes a 72-hour burn-in test and full DDM/DOM validation before shipment.

  • Up to 70% cost savings vs OEM, transparent pricing & flexible bulk rates, supported quality returns
  • 100% real-device compatible with Cisco, Huawei,Dell,Juniper, and Arista
  • ISO 9001:2015 Shenzhen factory, full lineup: 1.25G/10G/25G/40G/100G/200G/400G/800G/1.6T transceivers
  • Ample stock, fast global DHL/FedEx shipping in 3–5 working days
  • Free pre-sales engineering support for custom EEPROM  & private label firmware
  • Real switch test videos available for pre-purchase review; inspection & shipping videos provided per order


“Phenomenal performance. We deployed 200 HYTOPTODEVICE SFP modules to replace Cisco OEMs in our backbone network. Result? Zero compatibility issues and a 60% reduction in costs. Highly recommended for mission-critical networks."— Senior Network Engineer, Regional Telecom, Australia


Quality Certification & Compliance

 At HYTOPTODEVICE, our quality commitment is backed by industry-standard validations. From fiber optical transceiver manufacturing to final visual inspection, from IQC、IPQC、FQC to OQC, our processes ensure global compliance and reliability.

We adhere to rigorous standards for our SFP modules and network solutions:

  • ISO 9001: Certified quality management and production consistency.

  • CE & FCC: Fully compliant for seamless Global Market Access.

  • RoHS: Committed to environmental responsibility and hazardous material control.

  • Proven Reliability: Rigorous testing to reduce compliance risk and ensure safety.

Certified Quality. Global Standards. Guaranteed Performance.




Rigorous Industrial Product Testing

   hytoptodevice check device and equiptment for optical transceiver module

100% 3rd Party Compatible
testing device for hytoptodevice 10g sfp+ bidi optical module
Partial Test Demonstration
hytoptodevice compatible optical transceiver module for ethernet,data center
