Cisco QSFP-100G-CU5M Compatible 5m (16ft) 100G QSFP28 Passive DAC Cable | HYTOPTODEVICE

HYTOPTODEVICE factory supplier delivers reliable 100G QSFP28 passive DAC copper cable, 5m 100GBASE-CR4, pre-coded EEPROM for Cisco NX-OS. Zero-power, low latency twinax cable, bulk purchase for leaf-spine fabric, AI GPU cluster and HPC networking.
NO. Brand  Compatible P/N Transceiver Type
1 Cisco QSFP-100G-CU5M
2 Arista Networks  CAB-Q-Q-100G-5M
3 Juniper QFX-QSFP28-DAC-5M
4 Brocade 100G-Q28-Q28-C-0501
5 Dell  DAC-Q28-100G-5M
6 Huawei QSFP28-100G-CU5M
Description

Cisco QSFP-100G-CU5M Compatible 5m (16ft) 100G QSFP28 Passive DAC Cable | 100GBASE-CR4 Copper Twinax Bulk Wholesale | HYTOPTODEVICE

Product Overview

HYTOPTODEVICE 5m 100G QSFP28 passive DAC cable is a plug-and-play replacement for Cisco QSFP-100G-CU5M. Built per SFF-8662 and IEEE 802.3bj MSA standards, it adopts premium low-loss twinax copper for stable 100GBASE-CR4 transmission between two QSFP28 ports.
This direct attach cable features low power consumption, ultra-low latency and compact cabling layout. Passive architecture draws zero power without extra transceiver chips. Slim 26AWG twinax jacket supports 5-meter full MSA rated reach, hot-swap capable, ideal for leaf-spine fabrics, AI computing, HPC and storage networking.
We keep inventory for wholesalers, distributors and system integrators deploying Cisco NX-OS fabrics. Every cable is pre-programmed with Cisco-matched EEPROM signature to eliminate unsupported transceiver alerts. Batch signal integrity testing, bulk shipment and OEM private label are available for Cisco solution partners.

Key Technical Specifications

Cisco Compatible
 QSFP28-100G-CU5M
Vendor Name HYTOPTODEVICE
Connector QSFP28 to QSFP28 Max Data Rate 100Gbps
Cable Length 5m (16ft) Wire AWG AWG 26
Cable Type Passive Twinax Power Consumption ≤0.5W
Media Copper Operation Temperature 0~ 70 °C (32 to 158°F)
Jacket Material PVC(OFNR) Protocols QSFP28 MSA, SFF-8662, IEEE 802.3
Minimum Bend Radius 50mm Application 100 Gigabit Ethernet

For detailed technical specifications, please refer to the Datasheet


Usage Guidelines & Best Practices

  • Mandatory Port Setting: Host QSFP28 port must enable 100GBASE-CR4 mode; link negotiation failure will happen if forced to optical mode.

  • Cabling Requirements: Do not exceed the minimum 50mm bend radius, avoid sharp folding, heavy extrusion or long-term tension on the cable assembly.

  • Port Installation Standard: Works only with standard QSFP28 100G ports; cannot be inserted into SFP+ or XFP slots. Disable the host’s third-party transceiver lock policy in advance if required.

  • Maintenance Specification: Hot‑swap supported, grip the pull tab instead of pulling the cable body during plug/unplug to prevent internal conductor damage.

  • Testing & Storage: Run sample validation on target hardware before large bulk deployment; store spare cables in dry, dust‑free and anti‑static packaging.
  • Operating Environment: This commercial-grade cable operates reliably within 0℃‑70℃; avoid installation beside high-heat power modules.

For detailed operation instructions, please refer to the User Guide.


Full Compatibility List & Supported Devices

1. Validated Cisco Hardware & Firmware

  • Cisco Nexus 9300 series:N9K-C93180YC-FX, N9K-C9364C, N9K-C9336C-FX2
  • Cisco Nexus 9200 / 9500 series:N9K-C9232C, N9K-C9504, N9K-C9508
  • Cisco Catalyst 9500 series:C9500-16X, C9500-32C
  • Cisco UCS Servers:UCS C220, C240, C480 with VIC 1457, VIC1480 QSFP28 NIC
  • Firmware:NX-OS 9.3(8), 10.2(3), 10.5(2), 10.6(1)

2. Multi-Brand Cross Interoperability

Built on universal MSA open standards, this 100G QSFP28 passive copper twinax cable can interoperate with mainstream network brands including Arista, H3C, Juniper, Dell, NVIDIA Mellanox and more, for mixed-vendor rack stacking and server fabric expansion.

3. Free Value-Added Services

  • Custom firmware for multi-device compatibility
  • Support sample testing before bulk orders for project pre-verification
  • Private-label customization and professional deployment guidanc
  • Strict batch consistency quality control
  • Free custom EEPROM programming for special and legacy network environments
  • Free EEPROM rewriting (Tools Included) with 24/7 Tech Support

Primary Application Scenarios

• Intra-rack leaf-spine 100G fabric interconnection

• AI computing and GPU cluster short-range links
• HPC high-performance computing networking
• Storage array and top-of-rack switch connection
• 400G data center upgrade and migration
• Distributor stock and system integration projects

Connectivity Solutions(Applications)

1. 100G to 100G Direct Link for Switch-Switch
HYTOPTODEVICE QSFP-100G-CU1M compatible  100G QSFP28 passive DAC copper twinax cable in stock for wholesale buyers


2. 100G to 100G Direct Link for Switch-NIC
 100G QSFP28 passive DAC copper twinax cable for data center integrators


3.
Upgrade Solution for 400G Data Center Network





The Core Feature

1. Cost-Effective Ultra-Short Connectivity

Using twinax copper, the 100G passive copper cable replaces a fiber pair and two optical transceivers, significantly cutting interconnect cost for short-reach links — plug-and-play, no modules required.

2. Ultra-Low Power, Maximum Energy Efficiency

The 100g qsfp28 passive copper twinax cable draws near-zero power, reducing heat and energy costs in dense racks, while delivering a cost-effective, low-latency 100G link for short-reach connections — within a rack or across adjacent racks.


3.Host-Device Tested for Proven Interoperability

Every 100g passive copper twinax cable is rigorously tested for compatibility in the target switch environment, so you can deploy with confidence — no surprises, no downtime. Not sure it fits? Compatibility Video available upon request.

hytoptodevice wholesale 40G QSFP+ twinax cable for data center

4. 100% Individually Tested for Peak Performance

Every single unit is tested individually — no sampling, no shortcuts — to ensure optical compliance and continuous operational stability. Curious how we do it? Take a virtual tour of our Test Center.

HYTOPTODEVICE  QSFP+ to QSFP+ 40g qsfp+ dac cable for switches

FAQ

Q1: What is the maximum transmission distance supported by a 100G passive QSFP28 DAC cable? A: The industry maximum reach for 100GBASE-CR4 passive QSFP28 DAC is 5 meters. It is limited by copper insertion loss and crosstalk at 25G per lane, so HYTOPTODEVICE passive twinax DACs are offered in 0.5m,1m,1.5m,2m,3m,5m options within this limit.

Q2: Will my switch throw errors if I try to use a passive DAC beyond its rated length? A: Yes, link failures or CRC errors are very likely. Exceeding rated length pushes signal loss past the chip’s equalization budget. HYTOPTODEVICE only supplies DACs matched to the labeled length to avoid such instability.

Q3: Do shorter lengths (e.g., 0.5m or 1m) cause any signal reflection issues? A: Properly manufactured short passive DACs do not create reflection problems. HYTOPTODEVICE controls impedance tightly at 100Ω differential, and our short variants pass return loss testing to keep reflections within MSA specs.

Q4: Can I program or re-write the EEPROM/coding on these DAC cables myself? A: Standard off-the-shelf HYTOPTODEVICE DACs are pre-coded and locked for stability. We support customer requirements. We can supply coding tools, software and related services, and even provide remote guidance for you.

Q5: How often do firmware updates on switches break compatibility with third-party DAC cables? A: It happens occasionally on major OS releases when vendors tighten EEPROM validation rules. HYTOPTODEVICE keeps EEPROM profiles updated and validates against mainstream firmware versions to reduce this risk. We can assist customers with recoding when necessary.

Q6: What information does the supplier need from me to ensure correct switch compatibility before shipping? A: We need switch brand, exact model, OS version, and required PN to match the EEPROM. Share these details with HYTOPTODEVICE, and we will pre-test the profile before dispatch.

Q7: What kind of shielding is used to prevent cross-talk between high-speed internal lanes? A: Individually shielded twinaxial (SFP/QSFP twinax) copper pairs surrounded by an overall braid and foil shield prevent near-end and far-end crosstalk. This dual-layer design suppresses crosstalk and EMI for HYTOPTODEVICE high-speed DACs.

Q8: Are these cables tested for high-frequency signal integrity (Insertion Loss, Return Loss, Crosstalk) prior to shipping? A: Yes, every production batch runs TDR, insertion loss, return loss and crosstalk sampling. HYTOPTODEVICE rejects units out of spec to guarantee consistent signal integrity for 100G links.

Q9: Are the pull-tabs durable, or do they snap off easily under frequent unplugging? A: Our pull tabs use reinforced plastic overmolding and strain relief. Under normal hot-swap operation, they resist breakage; HYTOPTODEVICE designs them for repeated plug/unplug in dense data center racks.

Q10: Are the outer jackets rated for data center fire safety? A: Yes, the jacket material meets LSZH low-smoke zero-halogen requirements, suitable for data center aisle deployment. All HYTOPTODEVICE DAC jackets follow standard fire safety specifications.

Q11: How much cost savings can I expect by choosing DAC over optical transceivers and fiber? A: Typically you can save 40%–70% versus paired QSFP28 optics plus fiber patch cords for short rack links. HYTOPTODEVICE passive DAC removes optical component costs for same-rack leaf-spine connections.

Q12: When should I choose a 100G DAC cable instead of two QSFP28 transceivers and a fiber patch? A: Pick passive DAC for intra-rack links ≤5m where low latency, zero power and lower cost matter. Choose fiber optics when runs exceed 5m or you need isolation between racks or buildings.

Q13: What is your standard warranty and RMA policy for defective or non-compatible cables? A: HYTOPTODEVICE provides a 5-year warranty for manufacturing defects. If pre-coded cables fail compatibility due to our EEPROM profile, we support free RMA replacement after troubleshooting confirmation.

Q14: What are your lead times and minimum order quantities (MOQ) for custom-coded cables? A: Standard stocked DACs ship quickly. Custom EEPROM coded orders have flexible MOQ, we try our best to accommodate customer demands. Contact HYTOPTODEVICE sales for exact MOQ and schedule for your custom project.

Q15: Are your cables compliant with environmental and safety standards like RoHS, CE, FCC, and MSA? A: Yes, all HYTOPTODEVICE QSFP28 passive DAC cables are MSA compliant, RoHS, CE and FCC certified, suitable for global data center and enterprise network deployment.

Packaging & Custom OEM Solutions

  • ESD Protection & Fast Shipping: Every transceiver is sealed in an ESD-safe bag and ready for same-day dispatch from stock.

  • Custom OEM & Branding: We provide logo printing, private labeling, and custom packaging to help distributors and integrators build their brand—no factory investment required.


Why Network Engineers Choose HYTOPTODEVICE

HYTOPTODEVICE has supplied over 5000,000 optical transceiver modules to data centers, ISPs, and enterprise networks across 100+ countries since 2011. Every module undergoes a 72-hour burn-in test and full DDM/DOM validation before shipment.

  • Up to 70% cost savings vs OEM, transparent pricing & flexible bulk rates, supported quality returns
  • 100% real-device compatible with Cisco, Huawei,Dell,Juniper, and Arista
  • ISO 9001:2015 Shenzhen factory, full lineup: 1.25G/10G/25G/40G/100G/200G/400G/800G/1.6T transceivers
  • Ample stock, fast global DHL/FedEx shipping in 3–5 working days
  • Free pre-sales engineering support for custom EEPROM  & private label firmware
  • Real switch test videos available for pre-purchase review; inspection & shipping videos provided per order


“Phenomenal performance. We deployed 200 HYTOPTODEVICE SFP modules to replace Cisco OEMs in our backbone network. Result? Zero compatibility issues and a 60% reduction in costs. Highly recommended for mission-critical networks."— Senior Network Engineer, Regional Telecom, Australia


Quality Certification & Compliance

 At HYTOPTODEVICE, our quality commitment is backed by industry-standard validations. From fiber optical transceiver manufacturing to final visual inspection, from IQC、IPQC、FQC to OQC, our processes ensure global compliance and reliability.

We adhere to rigorous standards for our SFP modules and network solutions:

  • ISO 9001: Certified quality management and production consistency.

  • CE & FCC: Fully compliant for seamless Global Market Access.

  • RoHS: Committed to environmental responsibility and hazardous material control.

  • Proven Reliability: Rigorous testing to reduce compliance risk and ensure safety.

Certified Quality. Global Standards. Guaranteed Performance.
