Brocade 100G-Q28-Q28-C-0101 Compatible 1m (3ft) 100G QSFP28 Passive Dircet Attach Copper(DAC) Cable | HYTOPTODEVICE

HYTOPTODEVICE reliable factory supplier offers 100G QSFP28 Passive direct attach copper cable with low power consumption, high-speed direct-attach performance and compact cabling design. This 1m Brocade 100G-Q28-Q28-C-0101 compatible QSFP28 DAC cable is pre-coded for Brocade ICX and VDX switching platforms. Bulk purchase this high-performance DAC for low-latency intra-rack networking, storage and AI server interconnection.
NO. Brand  Compatible P/N Transceiver Type
1 Cisco QSFP-100G-CU1M
2 Arista Networks  CAB-Q-Q-100G-1M
3 Juniper QFX-QSFP28-DAC-1M
4 Brocade 100G-Q28-Q28-C-0101
5 Dell  DAC-Q28-100G-1M
6 Huawei QSFP28-100G-CU1M
7 H3C  QSFP-100G-D-CAB-1M
8 HPE BladeSystem  845404-B21
Description

Brocade 100G-Q28-Q28-C-0101 Compatible 1m (3ft) 100G QSFP28 Passive Direct Attach Copper(DAC) Cable | HYTOPTODEVICE

Product Overview

HYTOPTODEVICE 1m 100G QSFP28 Passive direct attach copper cable is a drop-in replacement for Brocade 100G-Q28-Q28-C-0101. Built following SFF-8662 and IEEE 802.3bj MSA standards, this high-speed direct-attach twinax cable delivers stable 100GBASE-CR4 bandwidth between two QSFP28 ports. It features zero low power consumption, compact cabling layout and hot-swap capability for non-disruptive maintenance on Brocade switch chassis.
We stock this 100G QSFP28 Passive direct attach copper cable for buyers, wholesalers and system integrators building Brocade enterprise and storage fabrics. Each cable is pre-programmed with Brocade matching EEPROM signatures to avoid unsupported transceiver alerts. Sampling, bulk order and OEM private label services are available for data center distributors and solution providers.

Key Technical Specifications

Brocade Compatible
 100G-Q28-Q28-C-0101
Vendor Name HYTOPTODEVICE
Connector QSFP28 to QSFP28 Max Data Rate 100Gbps
Cable Length 1m (3ft) Wire AWG AWG 30
Cable Type Passive Twinax Power Consumption ≤0.5W
Media Copper Operation Temperature 0~ 70 °C (32 to 158°F)
Jacket Material PVC(OFNR) Protocols QSFP28 MSA, SFF-8662, IEEE 802.3
Minimum Bend Radius 35mm Application 100 Gigabit Ethernet

For detailed technical specifications, please refer to the Datasheet


Usage Guidelines & Best Practices

  • Mandatory Port Setting: Host QSFP28 port must enable 100GBASE-CR4 mode; link negotiation failure will happen if forced to optical mode.

  • Cabling Requirements: Do not exceed the minimum 35mm bend radius, avoid sharp folding, heavy extrusion or long-term tension on the cable assembly.

  • Port Installation Standard: Works only with standard QSFP28 100G ports; cannot be inserted into SFP+ or XFP slots. Disable the host’s third-party transceiver lock policy in advance if required.

  • Maintenance Specification: Hot‑swap supported, grip the pull tab instead of pulling the cable body during plug/unplug to prevent internal conductor damage.

  • Testing & Storage: Run sample validation on target hardware before large bulk deployment; store spare cables in dry, dust‑free and anti‑static packaging.
  • Operating Environment: This commercial-grade cable operates reliably within 0℃‑70℃; avoid installation beside high-heat power modules.

For detailed operation instructions, please refer to the User Guide.


Full Compatibility List & Supported Devices

1. Validated Brocade Hardware & Firmware

  • Brocade SLX series:SLX 9150, SLX 9250, SLX 9540, SLX 9640, SLX 9850
  • Brocade VDX series:VDX 6740, VDX 6760, VDX 8770 (100G line card supported)
  • Brocade ICX series:ICX 7850-32C, ICX 7850-48F, ICX 7850-48C
  • Brocade SAN Directors & Storage Switches:X6-4, X6-8, G720, G730, G748
  • Firmware:Brocade Fabric OS v8.2.x, v9.0.x, v9.1.x, v9.2.x

2. Multi-Brand Cross Interoperability

Built on universal MSA open standards, this 100G QSFP28 passive direct attach copper cable can interoperate with mainstream network brands including Arista, H3C, Juniper, Dell, NVIDIA Mellanox and more, for mixed-vendor rack stacking and server fabric expansion.

3. Free Value-Added Services

  • Custom firmware for multi-device compatibility
  • Support sample testing before bulk orders for project pre-verification
  • Private-label customization and professional deployment guidanc
  • Strict batch consistency quality control
  • Free custom EEPROM programming for special and legacy network environments
  • Free EEPROM rewriting (Tools Included) with 24/7 Tech Support

Primary Application Scenarios
  • Brocade leaf-spine 100G fabric intra-rack high-speed interconnection
  • Short-distance links between storage arrays and Brocade top-of-rack switches
  • Direct replacement for original Brocade 100G-Q28-Q28-C-0101 100G QSFP28 Passive direct attach copper cable
  • Hyper-converged infrastructure and distributed storage backend cabling
  • Low latency 100G links for virtualization clusters and AI compute racks
  • Stock replenishment purchase for IT distributors and Brocade data center solution partners

Connectivity Solutions(Applications)

1. 100G to 100G Direct Link for Switch-Switch
HYTOPTODEVICE QSFP-100G-CU1M compatible  100G QSFP28 passive DAC copper twinax cable in stock for wholesale buyers


2. 100G to 100G Direct Link for Switch-NIC
 100G QSFP28 passive DAC copper twinax cable for data center integrators


3.
Upgrade Solution for 400G Data Center Network





The Core Feature

1. Cost-Effective Ultra-Short Connectivity

Using twinax copper, the 100G passive copper cable replaces a fiber pair and two optical transceivers, significantly cutting interconnect cost for short-reach links — plug-and-play, no modules required.

2. Ultra-Low Power, Maximum Energy Efficiency

The 100g qsfp28 passive copper twinax cable draws near-zero power, reducing heat and energy costs in dense racks, while delivering a cost-effective, low-latency 100G link for short-reach connections — within a rack or across adjacent racks.

QSFP+ form factor 40g qsfp+ dac cable with low power consumption

3.Host-Device Tested for Proven Interoperability

Every 100g passive copper twinax cable is rigorously tested for compatibility in the target switch environment, so you can deploy with confidence — no surprises, no downtime. Not sure it fits? Compatibility Video available upon request.

hytoptodevice wholesale 40G QSFP+ twinax cable for data center

4. 100% Individually Tested for Peak Performance

Every single unit is tested individually — no sampling, no shortcuts — to ensure optical compliance and continuous operational stability. Curious how we do it? Take a virtual tour of our Test Center.

HYTOPTODEVICE  QSFP+ to QSFP+ 40g qsfp+ dac cable for switches

FAQ

Q1: What physical factors decide the maximum working length of a 100G QSFP28 passive direct attach copper cable? A: Differential signal attenuation and impedance matching limit the reach of passive 100G DAC. HYTOPTODEVICE 100G QSFP28 Passive direct attach copper cable complies with MSA specs and supports reliable transmission up to 5 meters for intra-rack links.

Q2: Why do passive and active 100G direct attach copper cables differ in maximum cabling reach? A: Passive DAC contains no built-in signal conditioning chips and caps at 5m, while active DAC integrates retimers and equalizers to extend reach to 7–10m. HYTOPTODEVICE supplies both types so customers can select the right high-speed direct-attach cable for their rack layout.

Q3: What risks emerge if I run a 100G passive direct attach copper cable beyond its rated length? A: Exceeding the rated length will trigger link flapping, CRC errors or complete link down. Copper signal loss rises sharply once past the design limit. Every HYTOPTODEVICE 100G QSFP28 Passive direct attach copper cable carries clear length marking to avoid improper installation.

Q4: Can a 100G QSFP28 passive direct attach copper cable connect servers and switches across separate server rows? A: Passive 100G DAC is not suitable for cross-row connections, since inter-row runs usually exceed the 5m maximum limit. AOC or fiber cabling works better for row-to-row links; HYTOPTODEVICE passive DAC is optimized for compact within-rack cabling.

Q5: Do short 0.5m or 1m 100G QSFP28 passive direct attach copper cables create unwanted signal reflection? A: Properly manufactured short DAC maintains stable differential impedance and avoids harmful signal reflection. HYTOPTODEVICE runs eye diagram validation for each batch of short 100G QSFP28 Passive direct attach copper cable to guarantee high-speed signal integrity.

Q6: Will uncoded generic 100G QSFP28 DAC be recognized plug-and-play on locked Brocade, Cisco or Arista switches? A: Unprogrammed generic DAC normally triggers unsupported transceiver alerts on vendor-locked switching platforms. HYTOPTODEVICE preloads matched EEPROM signatures for Brocade, Cisco and Arista to achieve smooth plug-and-play deployment.

Q7: What tools are required to rewrite EEPROM coding for 100G QSFP28 direct attach copper cables onsite? A: A dedicated EEPROM programmer and matching coding software are required to modify DAC profiles. HYTOPTODEVICE can provide the programmer tool, software and remote technical guidance. Most buyers choose pre-coded cables to save time and prevent coding mistakes.

Q8: Does using third-party 100G QSFP28 passive direct attach copper cable automatically void Brocade switch OEM warranty? A: Most network OEMs will not invalidate full hardware warranty just for compatible third-party DAC, though faults caused by defective cabling may be excluded. Fully tested HYTOPTODEVICE 100G DAC reduces this risk for enterprise purchasers.

Q9: Why do Brocade OS firmware updates sometimes break compatibility with third-party 100G DAC cables? A: Major firmware releases occasionally strengthen transceiver authentication rules, requiring updated EEPROM profiles from the cable supplier. HYTOPTODEVICE keeps updating signature libraries to match new Brocade OS firmware builds.

Q10: What details should I provide to the supplier to guarantee perfect Brocade switch compatibility before shipment? A: You need to submit switch brand, exact model, running firmware version and target compatible OEM part number. Share these specs with HYTOPTODEVICE, and we will pre-program your 100G QSFP28 Passive direct attach copper cable before delivery.

Q11: What BER level can I expect from factory-tested 100G QSFP28 passive direct attach copper cables? A: HYTOPTODEVICE 100G QSFP28 Passive direct attach copper cable maintains BER below 1×10⁻¹² under full bandwidth load, meeting standard data center requirements. Batch signal testing ensures stable low-error high-speed fabric performance.

Q12: Why is this 100G QSFP28 passive direct attach copper cable not compatible with PAM4 signaling? A: This DAC is designed for 25G NRZ lanes for 100GBASE-CR4 and does not support PAM4 electrical characteristics. HYTOPTODEVICE provides separate PAM4-capable cable options for 400G projects upon request.

Q13: What shielding construction is used to reduce crosstalk between high-speed internal lanes of 100G DAC? A: Our 100G QSFP28 Passive direct attach copper cable adopts individual foil shielding per twinax pair plus overall braided shielding. This dual-layer design suppresses crosstalk and EMI inside dense high-speed server racks.

Q14: Do active 100G direct attach copper cables use retimer chips and show higher failure rates? A: Active 100G DAC relies on built-in retimer chips for signal recovery. Extra semiconductor components create more failure points than passive copper. HYTOPTODEVICE recommends passive DAC for short links thanks to low power consumption and better reliability.

Q15: What is the minimum safe bend radius for your 100G QSFP28 passive direct attach copper cable? A: The minimum bend radius for HYTOPTODEVICE 100G QSFP28 Passive direct attach copper cable is 35 mm. Bending tighter than this value deforms internal conductors and gradually raises bit error rates.

Packaging & Custom OEM Solutions

  • ESD Protection & Fast Shipping: Every transceiver is sealed in an ESD-safe bag and ready for same-day dispatch from stock.

  • Custom OEM & Branding: We provide logo printing, private labeling, and custom packaging to help distributors and integrators build their brand—no factory investment required.


Why Network Engineers Choose HYTOPTODEVICE

HYTOPTODEVICE has supplied over 5000,000 optical transceiver modules to data centers, ISPs, and enterprise networks across 100+ countries since 2011. Every module undergoes a 72-hour burn-in test and full DDM/DOM validation before shipment.

  • Up to 70% cost savings vs OEM, transparent pricing & flexible bulk rates, supported quality returns
  • 100% real-device compatible with Cisco, Huawei,Dell,Juniper, and Arista
  • ISO 9001:2015 Shenzhen factory, full lineup: 1.25G/10G/25G/40G/100G/200G/400G/800G/1.6T transceivers
  • Ample stock, fast global DHL/FedEx shipping in 3–5 working days
  • Free pre-sales engineering support for custom EEPROM  & private label firmware
  • Real switch test videos available for pre-purchase review; inspection & shipping videos provided per order


“Phenomenal performance. We deployed 200 HYTOPTODEVICE SFP modules to replace Cisco OEMs in our backbone network. Result? Zero compatibility issues and a 60% reduction in costs. Highly recommended for mission-critical networks."— Senior Network Engineer, Regional Telecom, Australia


Quality Certification & Compliance

 At HYTOPTODEVICE, our quality commitment is backed by industry-standard validations. From fiber optical transceiver manufacturing to final visual inspection, from IQC、IPQC、FQC to OQC, our processes ensure global compliance and reliability.

We adhere to rigorous standards for our SFP modules and network solutions:

  • ISO 9001: Certified quality management and production consistency.

  • CE & FCC: Fully compliant for seamless Global Market Access.

  • RoHS: Committed to environmental responsibility and hazardous material control.

  • Proven Reliability: Rigorous testing to reduce compliance risk and ensure safety.

Certified Quality. Global Standards. Guaranteed Performance.




Rigorous Industrial Product Testing

   hytoptodevice check device and equiptment for optical transceiver module

100% 3rd Party Compatible
testing device for hytoptodevice 10g sfp+ bidi optical module
Partial Test Demonstration
hytoptodevice compatible optical transceiver module for ethernet,data center
