Arista CAB-Q-Q-100G-2M Compatible 2m (7ft) 100G QSFP28 Direct Attach Copper(DAC) Cable | HYTOPTODEVICE

HYTOPTODEVICE factory supplier provides reliable 100G QSFP28 direct attach copper DAC cable with zero power draw and excellent signal integrity. This 2m Arista CAB-Q-Q-100G-2M compatible QSFP28 twinax cable is pre-coded for Arista EOS. Bulk purchase this DAC cable for low-latency intra-rack leaf-spine connections, storage networking and low-risk 400G data center migration.
NO. Brand  Compatible P/N Transceiver Type
1 Cisco QSFP-100G-CU2M
2 Arista Networks  CAB-Q-Q-100G-2M
3 Juniper QFX-QSFP28-DAC-2M
4 Brocade 100G-Q28-Q28-C-0201
5 Dell  DAC-Q28-100G-2M
6 Huawei QSFP28-100G-CU2M
Description

Arista CAB-Q-Q-100G-2M Compatible 1m (3ft) 100G QSFP28 Passive DAC Cable | HYTOPTODEVICE

Product Overview

HYTOPTODEVICE 2m 100G QSFP28 direct attach copper DAC cable is a plug-and-play replacement for Arista CAB-Q-Q-100G-2M. Manufactured to SFF-8662 and IEEE 802.3bj MSA specifications, this twinax cable delivers stable 100GBASE-CR4 bandwidth between paired QSFP28 ports. It adopts fully passive zero-power architecture, ultra-low latency and hot-swap capability to support non-disruptive maintenance for Arista switch chassis.
We maintain sufficient inventory of this 100G QSFP28 DAC cable for wholesalers, distributors and system integrators building Arista EOS-based data center fabrics. Each cable is pre-programmed with Arista-matched EEPROM signatures to eliminate unrecognized transceiver warning logs. Sample testing, bulk orders and OEM private label service are available for Arista solution partners.

Key Technical Specifications

Arista Compatible
 CAB-Q-Q-100G-2M
Vendor Name HYTOPTODEVICE
Connector QSFP28 to QSFP28 Max Data Rate 100Gbps
Cable Length 2m (7ft) Wire AWG AWG 30
Cable Type Passive Twinax Power Consumption ≤0.5W
Media Copper Operation Temperature 0~ 70 °C (32 to 158°F)
Jacket Material PVC(OFNR) Protocols QSFP28 MSA, SFF-8662, IEEE 802.3
Minimum Bend Radius 35mm Application 100 Gigabit Ethernet

For detailed technical specifications, please refer to the Datasheet


Usage Guidelines & Best Practices

  • Mandatory Port Setting: Host QSFP28 port must enable 100GBASE-CR4 mode; link negotiation failure will happen if forced to optical mode.

  • Cabling Requirements: Do not exceed the minimum 35mm bend radius, avoid sharp folding, heavy extrusion or long-term tension on the cable assembly.

  • Port Installation Standard: Works only with standard QSFP28 100G ports; cannot be inserted into SFP+ or XFP slots. Disable the host’s third-party transceiver lock policy in advance if required.

  • Maintenance Specification: Hot‑swap supported, grip the pull tab instead of pulling the cable body during plug/unplug to prevent internal conductor damage.

  • Testing & Storage: Run sample validation on target hardware before large bulk deployment; store spare cables in dry, dust‑free and anti‑static packaging.
  • Operating Environment: This commercial-grade cable operates reliably within 0℃‑70℃; avoid installation beside high-heat power modules.

For detailed operation instructions, please refer to the User Guide.


Full Compatibility List & Supported Devices

1. Validated Arista Hardware & Firmware

  • Arista 7060DX, 7060CX, 7280R, 7300X series EOS leaf & spine switches
  • Arista 7500R high-performance fabric switches
  • Arista 100G QSFP28 server adapter modules

2. Multi-Brand Cross Interoperability

Built on universal MSA open standards, this 100G QSFP28 passive copper twinax cable can interoperate with mainstream network brands including Arista, H3C, Juniper, Dell, NVIDIA Mellanox and more, for mixed-vendor rack stacking and server fabric expansion.

3. Free Value-Added Services

  • Custom firmware for multi-device compatibility
  • Support sample testing before bulk orders for project pre-verification
  • Private-label customization and professional deployment guidanc
  • Strict batch consistency quality control
  • Free custom EEPROM programming for special and legacy network environments
  • Free EEPROM rewriting (Tools Included) with 24/7 Tech Support

Primary Application Scenarios
  • Arista EOS leaf-spine 100G fabric intra-rack interconnection
  • Short rack links between servers and Arista top-of-rack switches
  • Direct replacement for original Arista CAB-Q-Q-100G-1M 100G QSFP28 passive dac cable
  • Hyper-converged storage and distributed storage backend cabling
  • 100G low-latency links for virtualization and AI compute pods
  • Stock replenishment purchase for IT distributors and Arista data center solution partners
  • Upgrade and expand data center for 400G migration

Connectivity Solutions(Applications)

1. 100G to 100G Direct Link for Switch-Switch
HYTOPTODEVICE QSFP-100G-CU1M compatible  100G QSFP28 passive DAC copper twinax cable in stock for wholesale buyers


2. 100G to 100G Direct Link for Switch-NIC
 100G QSFP28 passive DAC copper twinax cable for data center integrators


3.
Upgrade Solution for 400G Data Center Network





The Core Feature

1. Cost-Effective Ultra-Short Connectivity

Using twinax copper, the 100G passive copper cable replaces a fiber pair and two optical transceivers, significantly cutting interconnect cost for short-reach links — plug-and-play, no modules required.

2. Ultra-Low Power, Maximum Energy Efficiency

The 100g qsfp28 passive copper twinax cable draws near-zero power, reducing heat and energy costs in dense racks, while delivering a cost-effective, low-latency 100G link for short-reach connections — within a rack or across adjacent racks.

QSFP+ form factor 40g qsfp+ dac cable with low power consumption

3.Host-Device Tested for Proven Interoperability

Every 100g passive copper twinax cable is rigorously tested for compatibility in the target switch environment, so you can deploy with confidence — no surprises, no downtime. Not sure it fits? Compatibility Video available upon request.

hytoptodevice wholesale 40G QSFP+ twinax cable for data center

4. 100% Individually Tested for Peak Performance

Every single unit is tested individually — no sampling, no shortcuts — to ensure optical compliance and continuous operational stability. Curious how we do it? Take a virtual tour of our Test Center.

HYTOPTODEVICE  QSFP+ to QSFP+ 40g qsfp+ dac cable for switches

FAQ

Q1: What high-frequency electrical factors define the maximum usable transmission length of a 100G QSFP28 direct attach copper DAC cable? A: 25G per-lane signal attenuation and tight differential impedance control set the distance cap. HYTOPTODEVICE 100G QSFP28 direct attach copper DAC cable meets MSA specs and delivers reliable links up to 5 meters.

Q2: What internal design difference separates passive direct attach copper DAC from retimer-based active DAC? A: Passive direct attach copper DAC has no built-in signal recovery chips and maxes at 5m, while active DAC integrates retimers and equalizers to extend reach to 7–10m. HYTOPTODEVICE supplies both variants for different rack layout requirements.

Q3: What abnormal link behaviors appear if you deploy a 100G QSFP28 direct attach copper DAC cable beyond its rated length? A: Over-length deployment triggers intermittent link flapping, accumulating CRC counters or sudden link loss. Copper high-frequency attenuation rises rapidly beyond design limits. Every HYTOPTODEVICE 100G QSFP28 direct attach copper DAC cable has clear length marking to avoid misuse.

Q4: Can I run a 100G QSFP28 direct attach copper DAC cable to connect switches located in separate server rows? A: Direct attach copper DAC is not suitable for cross-row cabling, as inter-row runs commonly exceed the 5m limit. AOC or fiber is a better choice; HYTOPTODEVICE DAC cable is optimized for compact intra-rack connections.

Q5: Will this 2m 100G QSFP28 direct attach copper DAC cable introduce harmful signal reflection in high-speed 100G links? A: Precisely impedance-calibrated twinax construction suppresses unwanted reflection. HYTOPTODEVICE runs eye diagram validation on each batch of 100G QSFP28 direct attach copper DAC cable to guarantee stable signal quality.

Q6: Will generic unprogrammed 100G QSFP28 direct attach copper DAC cable work plug-and-play on locked Arista, Dell or HPE platforms? A: Generic uncoded DAC cables frequently trigger unsupported transceiver alerts on vendor-locked switches. HYTOPTODEVICE preloads matched EEPROM signatures for Arista EOS, Dell OS and HPE firmware for seamless plug-and-play operation.

Q7: What hardware and software kit do I need to rewrite EEPROM content on a 100G QSFP28 direct attach copper DAC cable on site? A: A dedicated EEPROM programmer plus matching coding software are required for local flashing. HYTOPTODEVICE can provide the programmer kit, software and remote technical guidance. Most bulk buyers choose pre-coded cables to reduce labor and eliminate programming faults.

Q8: Does using third-party 100G QSFP28 direct attach copper DAC cable automatically void Arista switch OEM warranty? A: Most OEMs will not void the entire hardware warranty just for compatible third-party DAC, but hardware damage caused by defective cabling may not be covered. Factory-tested HYTOPTODEVICE 100G QSFP28 direct attach copper DAC cable reduces this deployment risk.

Q9: Why do Arista EOS firmware upgrades sometimes fail to recognize third-party 100G direct attach copper DAC cable? A: Major EOS releases often strengthen transceiver authentication checks and demand updated EEPROM profiles. HYTOPTODEVICE continuously updates signature libraries to match new EOS firmware builds.

Q10: What information should I share with the supplier for accurate pre-coding for my Arista fabric? A: Prepare switch model, running EOS firmware release and target Arista part number. Submit these details to HYTOPTODEVICE, and we will pre-program your 100G QSFP28 direct attach copper DAC cable before bulk shipment.

Q11: What BER performance can I expect from factory-inspected 100G QSFP28 direct attach copper DAC cable? A: HYTOPTODEVICE 100G QSFP28 direct attach copper DAC cable maintains BER below 1×10⁻¹² under full 100G bandwidth load, satisfying standard data center requirements. Batch signal testing guarantees stable low-error leaf-spine operation.

Q12: Why is this 100G QSFP28 direct attach copper DAC cable incompatible with PAM4 signaling? A: This twinax cable is engineered for 25G NRZ lanes of 100GBASE-CR4 and lacks the electrical bandwidth required for PAM4. HYTOPTODEVICE can supply PAM4-capable cable solutions for 400G projects upon request.

Q13: How is the shielding structure built to reduce crosstalk within a 100G QSFP28 direct attach copper DAC cable? A: Our 100G QSFP28 direct attach copper DAC cable uses individual foil shielding for each twinax pair plus an outer braided shield. Dual-layer shielding suppresses crosstalk and EMI in dense high-density server racks.

Q14: Are active DAC cables fitted with retimer chips and carry higher failure risk than passive 100G QSFP28 direct attach copper DAC cable? A: Active DAC depends on retimer chips for signal recovery. Extra semiconductor components create more failure points compared with pure copper passive design. HYTOPTODEVICE recommends passive direct attach copper DAC cable for short rack links for superior long-term reliability.

Q15: What is the minimum safe bend radius for this 100G QSFP28 direct attach copper DAC cable? A: The minimum safe bend radius for HYTOPTODEVICE 100G QSFP28 direct attach copper DAC cable is 35 mm. Bending tighter than this value deforms internal conductors and gradually raises bit error rates during continuous runtime.

Packaging & Custom OEM Solutions

  • ESD Protection & Fast Shipping: Every transceiver is sealed in an ESD-safe bag and ready for same-day dispatch from stock.

  • Custom OEM & Branding: We provide logo printing, private labeling, and custom packaging to help distributors and integrators build their brand—no factory investment required.


Why Network Engineers Choose HYTOPTODEVICE

HYTOPTODEVICE has supplied over 5000,000 optical transceiver modules to data centers, ISPs, and enterprise networks across 100+ countries since 2011. Every module undergoes a 72-hour burn-in test and full DDM/DOM validation before shipment.

  • Up to 70% cost savings vs OEM, transparent pricing & flexible bulk rates, supported quality returns
  • 100% real-device compatible with Cisco, Huawei,Dell,Juniper, and Arista
  • ISO 9001:2015 Shenzhen factory, full lineup: 1.25G/10G/25G/40G/100G/200G/400G/800G/1.6T transceivers
  • Ample stock, fast global DHL/FedEx shipping in 3–5 working days
  • Free pre-sales engineering support for custom EEPROM  & private label firmware
  • Real switch test videos available for pre-purchase review; inspection & shipping videos provided per order


“Phenomenal performance. We deployed 200 HYTOPTODEVICE SFP modules to replace Cisco OEMs in our backbone network. Result? Zero compatibility issues and a 60% reduction in costs. Highly recommended for mission-critical networks."— Senior Network Engineer, Regional Telecom, Australia


Quality Certification & Compliance

 At HYTOPTODEVICE, our quality commitment is backed by industry-standard validations. From fiber optical transceiver manufacturing to final visual inspection, from IQC、IPQC、FQC to OQC, our processes ensure global compliance and reliability.

We adhere to rigorous standards for our SFP modules and network solutions:

  • ISO 9001: Certified quality management and production consistency.

  • CE & FCC: Fully compliant for seamless Global Market Access.

  • RoHS: Committed to environmental responsibility and hazardous material control.

  • Proven Reliability: Rigorous testing to reduce compliance risk and ensure safety.

Certified Quality. Global Standards. Guaranteed Performance.




Rigorous Industrial Product Testing

   hytoptodevice check device and equiptment for optical transceiver module

100% 3rd Party Compatible
testing device for hytoptodevice 10g sfp+ bidi optical module
Partial Test Demonstration
hytoptodevice compatible optical transceiver module for ethernet,data center
