Cisco QSFP-4X10G-AOC20M Compatible 40G QSFP+ to Four SFP+ Active Optical Cable AOC Wholesale | HYTOPTODEVICE

HYTOPTODEVICE supplies QSFP+ to Four SFP+ Active Optical Cable AOC Wholesale, Cisco QSFP-4X10G-AOC20M compatible 20m 40G QSFP+ to four SFP+ breakout AOC, 40G split into 4×10G lanes, 850nm multimode fiber, EMI immune, hot pluggable with DDM monitoring. Custom EEPROM programming and private label available. Suitable for long-distance inter-rack connections in data centers, server aggregation and SAN interconnection. Samples available, flexible MOQ for bulk wholesale procurement.
NO. Brand  Compatible P/N Transceiver Type
1 Cisco  QSFP-4X10G-AOC20M
2 Arista Networks QSFP-4X10G-AOC20M
3  Dell  CBL-QSFP-4X10G-AOC20M
4 Juniper Networks  JNP-QSFP-AOCBO-20M
5 Extreme 10GB-4-F20-QSFP
6 H3C QSFP-4X10G-D-AOC-20M
7 Brocade  40G-QSFP-4SFP-AOC-2001
Description

Cisco QSFP-4X10G-AOC20M Compatible 40G QSFP+ to Four SFP+ Active Optical Cable AOC Wholesale | HYTOPTODEVICE

Product Overview

HYTOPTODEVICE offers QSFP+ to Four SFP+ Active Optical Cable AOC Wholesale. This Cisco QSFP-4X10G-AOC20M compatible 20m breakout AOC converts one 40G QSFP+ port into four independent 10G SFP+ channels, adopting 850nm VCSEL multimode fiber for reliable long-span data center cabling. It works perfectly for long inter-rack links within climate-controlled server rooms. We support private label, custom EEPROM programming, sample testing and bulk wholesale orders. Every cable passes strict functional testing before delivery.

Key Technical Specifications

Cisco Compatible
 QSFP-4X10G-AOC20M
Vendor Name HYTOPTODEVICE
Connector QSFP+ to 4 SFP+ Max Data Rate 40Gbps
Operating Wavelength 850nm Fiber Cable OM3 MMF
Cable Length 20m (66ft) Power Consumption ≤1.4W
Jacket Material OFNP Operation Temperature 0~ 70 °C (32 to 158°F)
Minimum Bend Radius 30mm Protocols 10G/40Gigabit Ethernet or Fibre Channel
Application
InfinibandQDR/DDR/SDR,40G Ethernet,Data Center,Fibre
Channel
Warranty 5 Years

For detailed technical specifications, please refer to the Datasheet


Usage Guidelines & Best Practices

  • Mandatory Port Breakout Configuration: Ensure the host QSFP+ port supports channelization. Enable breakout mode (4x10G) via the switch CLI before connecting the cable.

  • Cabling Requirements: Do not exceed the minimum 30mm bend radius, avoid sharp folding, heavy extrusion or long-term tension on the cable assembly.

  • Port Installation Standard: Do not mix this breakout AOC with straight QSFP+ to QSFP+ AOC configuration.

  • Hot‑swap rule:Never pull or tug directly on the individual breakout legs. Always use the integrated pull-tab or bale latch when inserting or removing connectors.

  • Testing & Storage: Run sample validation on target hardware before large bulk deployment; store spare cables in dry, dust‑free and anti‑static packaging.
  • Operating Environment: 0‑70℃, indoor cabinet deployment only.

For detailed operation instructions, please refer to the User Guide.


Full Compatibility List & Supported Devices

1. Validated Cisco Hardware & Firmware

  • Cisco Nexus 9000 Series: N9K-C93180YC-FX, N9K-C93240YC-FX2
  • Cisco Nexus 5000/5500 Series: N5K-C5596UP, N5K-C5548UP
  • Cisco Nexus 3000 Series: N3K-C3232C, N3K-C3172PQ
  • Cisco UCS 6400 Fabric Interconnects: UCS-FI-6454
  • Cisco MDS 9000 Series: MDS 9706, MDS 9250i
  • Cisco Catalyst 9500 Series: C9500-32C, C9500-48Y4C

2. Multi-Brand Cross Interoperability

 Built on MSA open standards, this QSFP+ to Four SFP+ Active Optical Cable AOC supports mixed-vendor networking devices. can interoperate with mainstream network brands including Arista, Brocade, Juniper, Dell, H3C and Fortinet, for mixed-vendor rack stacking and server fabric expansion.

3. Free Value-Added Services

  • Custom firmware for multi-device compatibility
  • Support sample testing before bulk orders for project pre-verification
  • Private-label customization and professional deployment guidanc
  • Strict batch consistency quality control
  • Free custom EEPROM programming for special and legacy network environments
  • Free EEPROM rewriting (Tools Included) with 24/7 Tech Support

Primary Application Scenarios
  • Long inter-rack 40G to 4×10G breakout uplink in data centers
  • HPC cluster server node aggregation
  • SAN storage network port expansion
  • Enterprise switch fabric 10G server access
  • Leaf-spine long-range breakout interconnection

Connectivity Solutions(Applications)

1. 40G to 4x10G Breakout Link for Switch-Switch
hytoptodevice compatible qsfp to four sfp+ active optical breakout cables for 40g switch to swtich

The Core Feature

1. High Density & Low Power 40G Connectivity for Data Center

Lightweight fiber construction and low power consmuption, easy for high-density cable management in data center.



2.Host-Device Tested for Proven Interoperability

Each 40G QSFP+  AOC breakout cable is validated on actual host switches before delivery — instant link-up, zero surprises, zero downtime, guaranteeing flawless operation. Not sure it fits? Compatibility Video available upon request.


3. 100% Individually Tested for Peak Performance

Every single unit is tested individually — no sampling, no shortcuts — to ensure optical compliance and continuous operational stability. Curious how we do it? Take a virtual tour of our Test Center.

HYTOPTODEVICE  40g QSFP+ to 4 x sfp+ passive dac cable for switches

FAQ

Q1: What bending protection rules should I follow when routing the four breakout tails of this 20m AOC? A: Keep the bend radius above roughly 30mm at all times. Overly tight bends will crack internal glass fibers and permanently break the link of this QSFP+ to Four SFP+ Active Optical Cable AOC you source for wholesale projects.

Q2: Can this 40G breakout AOC sustain full bidirectional 40Gbps bandwidth across all four lanes concurrently? A: Yes, it delivers full wire-speed 40Gbps aggregate throughput in both directions, with four separate 10Gbps channels running independently without bandwidth throttling.

Q3: Will the 20-meter transmission span bring excessive jitter and degrade the optical signal quality? A: No. Built-in CDR circuits inside the optical transceivers actively eliminate jitter and keep the bit error rate ultra-low for stable long-distance data transmission.

Q4: Can I configure individual breakout ports to run different network speeds for mixed-rate deployments? A: No. The 40G QSFP+ port is fixed to split into four 10G channels. Each SFP+ breakout leg cannot be adjusted to 1G or 25G speeds separately.

Q5: What switch alert messages indicate an EEPROM coding mismatch on Cisco-compatible breakout AOC? A: Common warning logs include "Unsupported transceiver detected", "Security checksum error", or "Unqualified optic detected", which point to incorrect vendor programming.

Q6: Are these 10G SFP+ breakout tails compatible with older 1G SFP ports on legacy Cisco switching hardware? A: No. SFP+ interfaces are engineered for native 10G operation and cannot auto-negotiate down to match 1G SFP port speeds.

Q7: What outcome will occur if I plug the QSFP+ main connector into a 100G QSFP28 port by mistake? A: QSFP+ follows 40G electrical specifications. It cannot establish stable connectivity in a 100G QSFP28 port unless paired with dedicated down-conversion adapters.

Q8: How do I verify the Cisco switch has successfully discovered all four breakout sub-channels? A: Run CLI commands such as show interface status or show inventory, to confirm all four breakout sub-interfaces are listed on the switch port table.

Q9: Is daisy-chaining multiple breakout AOCs acceptable to extend the total cabling reach for wholesale data center projects? A: No. Active optical breakout cables cannot be cascaded together. Series interconnection breaks the optical path and triggers complete link failure.

Q10: What checks should I perform when only three out of four breakout links come up after installation? A: Double-check the switch channelization profile, reseat each SFP+ connector firmly, and analyze DOM diagnostic data to identify the faulty optical lane.

Q11: Will heavy pressure or being stepped on ruin the internal fiber strands hidden inside this breakout AOC? A: Yes. Crushing force can fracture internal glass fibers. The outer jacket may look undamaged, while the optical transmission path is already permanently destroyed.

Q12: Does this 20-meter long breakout AOC carry enough weight to create port sagging on Cisco switch cages? A: No. AOC fanout cables are far lighter than copper breakout alternatives, removing mechanical stress and port sag issues on switch hardware.

Q13: Is on-site splicing or repair possible if the cable jacket gets pinched or cut during rack installation? A: No. Transceivers are pre-integrated into the cable assembly. Field splicing is not practical, and damaged units require full replacement.

Q14: What support options are available if the wholesale breakout AOC arrives with incorrect vendor EEPROM coding? A: As your wholesale supplier for QSFP+ to Four SFP+ Active Optical Cable AOC, HYTOPTODEVICE provides exchange, return or re-programming services for coding compatibility issues upon delivery.

Q15: Can I order custom non-standard lengths instead of stocked standard sizes for large wholesale data center orders? A: Standard lengths including 1m,3m,5m,10m,15m,20m,30m,50m are kept in stock. Custom lengths are available for enterprise wholesale orders subject to MOQ requirements.


Packaging & Custom OEM Solutions

  • ESD Protection & Fast Shipping: Every transceiver is sealed in an ESD-safe bag and ready for same-day dispatch from stock.

  • Custom OEM & Branding: We provide logo printing, private labeling, and custom packaging to help distributors and integrators build their brand—no factory investment required.



Why Network Engineers Choose HYTOPTODEVICE

HYTOPTODEVICE has supplied over 5000,000 optical transceiver modules to data centers, ISPs, and enterprise networks across 100+ countries since 2011. Every module undergoes a 72-hour burn-in test and full DDM/DOM validation before shipment.

  • Up to 70% cost savings vs OEM, transparent pricing & flexible bulk rates, supported quality returns
  • 100% real-device compatible with Cisco, Huawei,Dell,Juniper, and Arista
  • ISO 9001:2015 Shenzhen factory, full lineup: 1.25G/10G/25G/40G/100G/200G/400G/800G/1.6T transceivers
  • Ample stock, fast global DHL/FedEx shipping in 3–5 working days
  • Free pre-sales engineering support for custom EEPROM  & private label firmware
  • Real switch test videos available for pre-purchase review; inspection & shipping videos provided per order


“Phenomenal performance. We deployed 200 HYTOPTODEVICE SFP modules to replace Cisco OEMs in our backbone network. Result? Zero compatibility issues and a 60% reduction in costs. Highly recommended for mission-critical networks."— Senior Network Engineer, Regional Telecom, Australia


Quality Certification & Compliance

 At HYTOPTODEVICE, our quality commitment is backed by industry-standard validations. From fiber optical transceiver manufacturing to final visual inspection, from IQC、IPQC、FQC to OQC, our processes ensure global compliance and reliability.

We adhere to rigorous standards for our SFP modules and network solutions:

  • ISO 9001: Certified quality management and production consistency.

  • CE & FCC: Fully compliant for seamless Global Market Access.

  • RoHS: Committed to environmental responsibility and hazardous material control.

  • Proven Reliability: Rigorous testing to reduce compliance risk and ensure safety.

Certified Quality. Global Standards. Guaranteed Performance.




Rigorous Industrial Product Testing

   hytoptodevice check device and equiptment for optical transceiver module

100% 3rd Party Compatible
testing device for hytoptodevice 10g sfp+ bidi optical module
Partial Test Demonstration
hytoptodevice compatible optical transceiver module for ethernet,data center


Application and Manufacturing Process
